Product Overview
When signal integrity is critical in harsh industrial environments, the Bently Nevada 125065-NN provides a robust connection solution. This two-conductor 18 AWG twisted, shielded cable features a two-socket plug with a fluorosilicone elastomer boot at one end and terminal lugs at the other, ensuring reliable data transmission in vibration monitoring and other sensitive applications.
Key Specifications
- Conductor: Two-conductor 18 AWG twisted, shielded
- Connector A: Two-socket plug with fluorosilicone elastomer boot
- Connector B: Terminal lugs
- Minimum Length: 2.0 ft (0.6 m)
- Maximum Length: 99 ft (30 m)
Industry Applications
The 125065-NN is ideal for connecting Bently Nevada sensors to monitoring systems in industries such as oil and gas, power generation, and heavy manufacturing. Its shielded twisted-pair construction minimizes electromagnetic interference, making it suitable for long cable runs up to 99 feet. The fluorosilicone elastomer boot provides resistance to oils and chemicals, extending service life in demanding environments.
Installation and Setup Guidance
When installing the 125065-NN, ensure the two-socket plug is securely mated with the sensor or module. Route the cable away from high-voltage lines to maintain signal integrity. The terminal lugs simplify field wiring to termination panels. For best performance, use the minimum practical cable length to reduce signal attenuation.
Maintenance and Reliability
The shielded design and robust boot material contribute to long-term reliability. Periodically inspect the cable for cuts, abrasions, or damage to the boot. Replace the cable if any wear is observed to prevent signal degradation. The 18 AWG conductor size offers a good balance of flexibility and strength for permanent installations.
Compatibility and Integration
This cable is designed for use with Bently Nevada sensors and monitoring systems that accept a two-socket plug connector. It is compatible with various transducers and modules requiring shielded twisted-pair connections. Verify the connector type on your equipment before ordering.
Selection Guide and Purchasing Advice
Before purchasing the 125065-NN, measure the required distance between the sensor and the monitoring system. Choose a length that provides some slack for routing but avoids excessive coiling. SpareTechPLC stocks this cable in multiple lengths to meet your exact needs. Contact our team for assistance with length selection and availability.
Frequently Asked Questions
What is the maximum length available for the 125065-NN?
The maximum length is 99 ft (30 m).
Is the cable shielded?
Yes, it is a twisted, shielded cable to reduce electrical noise.
What type of connector is on the sensor end?
It features a two-socket plug with a fluorosilicone elastomer boot.
Can I use this cable with other brands of sensors?
It is designed for Bently Nevada systems; verify connector compatibility with your equipment.
What is the conductor size?
The conductor is 18 AWG, twisted pair.
