171CCC96020 Modicon Momentum Processor Adapter Module Overview

Reliable Processing for Modicon Momentum Systems

When you are responsible for maintaining a Modicon Momentum automation platform, the processor adapter module is the heart of your control system. The Schneider Electric 171CCC96020 serves as an M1/M1E processor adapter, engineered to handle communication and processing tasks with dependable performance. For maintenance engineers, this module offers a straightforward path to keeping production lines running smoothly.

This adapter is part of the Modicon Momentum product line and is designed for integrated I/O operations. It features one Ethernet port and one input/output bus port, providing versatile connectivity for your control network. With a clock frequency of 50 megahertz, it ensures rapid data handling capabilities that support time-sensitive industrial processes.

Key Technical Specifications for Maintenance Planning

Understanding the technical specifications of the 171CCC96020 is essential for effective maintenance and troubleshooting. The module operates with a rated supply voltage of 5.0 V DC +/-5%, supplied by the Momentum I/O base. This low-voltage design simplifies power requirements and reduces heat generation, contributing to long-term reliability.

Memory is a critical aspect of any processor module. The 171CCC96020 provides 512 kilobytes of flash memory and 544 kilobytes of RAM, allowing for the storage of essential data and instructions. The memory description includes 18 kB of LL984 program memory and 24 kB of data, giving you a clear picture of the available resources for your control logic.

The processor capacity is designed to handle substantial I/O loads. It supports a discrete I/O processor capacity of 8,192 bits maximum and a register I/O processor capacity of 26,048 words maximum. This capacity ensures that the module can manage complex control schemes without compromising performance.

Environmental Durability and Installation Considerations

Industrial environments can be harsh, and the 171CCC96020 is built to withstand challenging conditions. It operates in ambient temperatures ranging from 0 to 60°C (32 to 140°F) in a non-condensing environment. For storage, it can endure temperatures from -40 to 85°C (-40 to 185°F), making it suitable for facilities with varying climate conditions.

Relative humidity tolerance is specified at 5 to 96% without condensation, which is typical for control equipment. The module also has a shock resistance rating of <= 15 gn peak with an 11 ms half sine wave acceleration, and vibration resistance of 0.75 mm d.a at 1 gn. These ratings give maintenance teams confidence in the module's mechanical robustness.

Integration and Communication Capabilities

The 171CCC96020 supports Ethernet communication, which is a standard in modern industrial networks. It provides one Ethernet port and one I/O bus port, enabling seamless integration with existing Modicon Momentum systems. The communication protocol is Ethernet, and the module supports services such as I/O scanning and Modbus TCP messaging, as indicated in the product data.

For software compatibility, the module works with Concept V2.6, Modsoft >= V2.5, ProWORX NxT V2.0, and ProWORX 32. This broad software support simplifies programming and maintenance, allowing engineers to use familiar tools. The processor is X86 based (INTEL, AMD), which is a well-known architecture in the automation industry.

Real-World Application Example

In a typical material handling application, the 171CCC96020 can manage conveyor control and sorting operations. Its 8,192-bit discrete I/O capacity allows it to handle numerous sensors and actuators, while the Ethernet port enables communication with a supervisory system. This setup helps maintain efficient throughput and reduces downtime.

Another common use is in packaging lines where precise timing is critical. The module's 50 MHz clock frequency and 0.3 milliseconds per kilobyte scan time (as per the full description) ensure responsive control. Maintenance engineers appreciate the module's robust design, which minimizes the need for frequent replacements.

Why Choose AutoDCSTech for Your Automation Needs

AutoDCSTech is your reliable source for industrial automation spare parts, including the Schneider 171CCC96020. We understand the importance of uptime, so we stock quality components to support your maintenance operations. Our team is ready to assist you with product selection and availability.

When you order from AutoDCSTech, you get genuine parts backed by our commitment to customer satisfaction. We offer competitive pricing and fast shipping to minimize your downtime. Contact us today to ensure your Modicon Momentum system remains operational.

Frequently Asked Questions

What is the function of the 171CCC96020 module?

The 171CCC96020 is an M1/M1E processor adapter module for the Modicon Momentum series. It facilitates communication and processing tasks, with one Ethernet port and one I/O bus port for integrated I/O operations.

What are the memory specifications of the 171CCC96020?

The module provides 512 kilobytes of flash memory and 544 kilobytes of RAM. It also includes 18 kB of LL984 program memory and 24 kB of data, as per the product description.

What is the operating temperature range for the 171CCC96020?

The module operates in ambient temperatures from 0 to 60°C (32 to 140°F) in a non-condensing environment. For storage, it can withstand temperatures from -40 to 85°C (-40 to 185°F).

How does the 171CCC96020 connect to a network?

It supports Ethernet communication with one Ethernet port and one I/O bus port. The communication protocol is Ethernet, and it supports services like I/O scanning and Modbus TCP messaging.

What is the supply voltage for the 171CCC96020?

The rated supply voltage is 5.0 V DC +/-5%, supplied by the Momentum I/O base. This low voltage is typical for processor adapter modules in this series.

Conclusion

The Schneider Electric 171CCC96020 is a dependable processor adapter module for Modicon Momentum systems. Its robust specifications, including 50 MHz clock frequency and substantial memory, make it a solid choice for industrial automation. For maintenance engineers, this module offers reliability and ease of integration.

Ensure your automation systems run efficiently by choosing the 171CCC96020 from AutoDCSTech. We provide quality parts and expert support to keep your operations running. Contact us for more information or to place an order.
