High-Performance Motion Control for Demanding Applications
In modern manufacturing, precise motion control directly impacts product quality and throughput. The B&R 8LSC53.ee022ff00-4 is a three-phase synchronous servo motor designed to meet these demands. It delivers excellent dynamic characteristics and positioning precision in a compact, lightweight package.
This motor is part of the 8LSC series, known for its permanent-magnet, electronically commutated design. It offers a large overload capacity and optimized torque rippling for good controllability. These features make it a strong choice for applications requiring high performance and reliability.
Key Technical Specifications of the 8LSC53.ee022ff00-4
The 8LSC53.ee022ff00-4 provides a balanced set of performance parameters. It has a nominal speed of 2200 rpm and a maximum speed of 5000 rpm. The motor delivers a nominal torque of 13.3 Nm and a stall torque of 15.6 Nm, ensuring robust operation under varying loads.
With a nominal power of 3055 W and a nominal current of 6.0 A, this motor handles substantial workloads efficiently. The maximum torque reaches 30.0 Nm, supported by a maximum current of 20.5 A. These figures indicate a strong overload capability, which is critical for applications with peak load demands.
The motor's torque constant is 2.22 Nm/A, and its voltage constant is 134.04 V/1000 rpm. The stator resistance is 2.54 Ohm, and the stator inductance is 29.6 mH. These electrical parameters ensure predictable performance and ease of control with compatible drives.
Mechanical and Environmental Robustness
The 8LSC53.ee022ff00-4 is built to operate in demanding industrial environments. It has an IP64 protection rating per EN 60034-5, with the fan rated at IP20. An optional oil seal can upgrade the motor to IP65, providing additional protection against dust and moisture.
The motor operates within an ambient temperature range of -15 to +40 degrees Celsius, with a maximum of +55 degrees Celsius. It can be used at elevations up to 2000 meters. The insulation class is F per IEC 60085, and the motor meets vibration severity A1 per EN 60034-14.
Cooling is provided by an externally fan-cooled system with a machine-mounted independent fan component, rated IC4A0A6. The fan is available in 24 VDC or 230 VAC versions, with noise levels specified per size. This design ensures consistent thermal performance even during continuous operation.
Integration with ACOPOS Servo Drives
The 8LSC53.ee022ff00-4 is designed to work seamlessly with B&R ACOPOS servo drives. The recommended drive series is 8X8X, which provides the necessary control and power for optimal motor performance. This pairing ensures reliable operation and simplifies system integration.
The motor supports both resolver and EnDat feedback systems, including safety-related variants. A single-cable hybrid solution is available, reducing wiring complexity and installation time. This integration capability makes the motor suitable for a wide range of automation architectures.
Real-World Application Scenarios
In a typical packaging line, the 8LSC53.ee022ff00-4 can drive a rotary cutting station. Its high maximum torque of 30.0 Nm allows it to handle sudden load changes during cutting cycles. The motor's compact size and reduced weight simplify machine design and reduce overall footprint.
In a material handling application, the motor's precise positioning capabilities ensure accurate placement of goods. The large overload capacity helps maintain performance during peak demand periods. These characteristics contribute to higher throughput and reduced downtime.
Frequently Asked Questions
What is the nominal torque of the 8LSC53.ee022ff00-4?
The nominal torque is 13.3 Nm, with a stall torque of 15.6 Nm. This provides a solid foundation for applications requiring consistent torque output.
What is the maximum speed of this motor?
The maximum speed is 5000 rpm, while the nominal speed is 2200 rpm. This wide speed range allows for flexible operation across different process requirements.
What feedback options are available?
The motor supports resolver and EnDat feedback systems, including safety-related variants. A single-cable hybrid solution is also available for simplified wiring.
What is the recommended servo drive for this motor?
The recommended servo drive is the ACOPOS series, specifically the 8X8X model. This drive ensures optimal performance and seamless integration.
