Product Overview
When vibration monitoring systems fail due to cable damage, the Bently Nevada 200151-60-02-02 provides a robust solution. This accelerometer interface standard cable, with connectors on both ends, ensures reliable signal transmission in harsh industrial environments. Designed for maintenance engineers who prioritize uptime, this 6.0-meter cable simplifies installation and reduces troubleshooting time.
Technical Specifications Breakdown
The 200151-60-02-02 cable features a 4-conductor, 22 AWG construction with a braided shield and drain wire, offering 85% minimum coverage for excellent noise immunity. The PVC outer jacket provides durability, while the nickel-plated coupling nuts resist corrosion. The cable operates reliably between -20 ºC and +100 ºC, and can be used at lower temperatures if not flexed. The minimum bend radius is 63.5 mm (2.5 in), allowing tight routing in control cabinets.
Industry Applications
This cable is ideal for connecting accelerometers to monitoring systems in rotating machinery, such as turbines, pumps, and compressors. In a typical installation, the 200151-60-02-02 ensures accurate vibration data transmission, preventing false alarms and reducing unplanned downtime. The IP67 seal protects against moisture ingress, making it suitable for outdoor or washdown environments.
Installation & Setup Guidance
For best results, route the cable away from high-voltage lines and sharp edges. The molded connectors provide a secure IP67 seal to transducers and mating hardware. Apply DC4 electrical insulating compound in the connectors for additional moisture protection during thermal shock. Verify the cable length (6.0 meters) meets your layout needs before installation.
Maintenance & Reliability
Inspect the cable periodically for cuts or abrasions on the PVC jacket. The braided shield and drain wire maintain signal integrity over time. The nylon coupling nut (armor option 02) resists chemical exposure, extending service life. Regular checks of the connector seals ensure continued IP67 protection, reducing the risk of vibration data loss.
Selection Guide & Purchasing Advice
Before ordering, confirm your system requires a 6.0-meter cable with connectors on both ends. The 200151-60-02-02 includes a blue cable without armor and a nylon coupling nut. For other lengths or armor options, consult the Bently Nevada 200151 series. SpareTechPLC stocks this model for fast delivery, ensuring minimal downtime for your maintenance projects.
Frequently Asked Questions
What is the operating temperature range of the 200151-60-02-02?
The cable operates from -20 ºC to +100 ºC (-4 ºF to +212 ºF). It can be used at lower temperatures if not flexed or bent.
Does this cable provide an IP67 seal?
Yes, the connectors provide an IP67 seal to transducers and mating hardware, with molded construction for moisture protection.
What is the minimum bend radius of the 200151-60-02-02?
The minimum bend radius is 63.5 mm (2.5 in), allowing flexible routing in tight spaces.
What type of connector does the cable use?
The cable has connectors on both ends with nickel-plated coupling nuts, ensuring secure connections.
Is the cable shielded?
Yes, it features a 4-conductor, 22 AWG construction with a braided shield and drain wire (85% minimum coverage) for noise reduction.
