Technical Specifications Breakdown
Key parameters for the 330101-00-08-05-02-05 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Product Type | 3300 XL 8 mm Probe, 3/8-24 UNF thread, without armor |
| Unthreaded Length Option | 00 - 0.0 in |
| Overall Case Length Option | 08 - 0.8 in |
| Total Length Option | 05 - 0.5 meter (1.6 feet) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector, standard cable |
| Approvals | CSA, ATEX, IECEx |
| Nominal Probe DC Resistance (0.5 m) | 7.45 ± 0.50 Ω |
| Linear Range | 2 mm (80 mils), from 0.25 to 2.3 mm (10 to 90 mils) |
| Incremental Scale Factor (ISF) - Standard 5 or 1 meter System | 7.87 V/mm (200 mV/mil) ± 5% |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Probe Temperature Range (Standard) | -52°C to +177°C (-62°F to +350°F) |
Industry Applications for the 3300 XL Probe
The 8 mm diameter provides a thicker PPS encapsulation for superior coil protection, reducing downtime from probe damage. With a linear range of 2 mm (80 mils) and an ISF of 7.87 V/mm, it delivers consistent data for predictive maintenance programs.
Installation & Setup Guidance
When installing the probe, ensure the target surface is clean and within the recommended gap setting of -9 Vdc (approximately 1.27 mm or 50 mils) for radial vibration. Use the miniature coaxial ClickLoc connector for secure, quick connections. Field wiring should use 3-conductor shielded triad cable, 0.2 to 1.5 mm² (16 to 24 AWG), with a maximum length of 305 meters (1,000 feet) between the Proximitor Sensor and monitor.
Maintenance & Reliability
The patented TipLoc and CableLoc designs provide a robust bond and 330 N (75 lbf) pull strength, reducing cable failures. The stainless steel case resists corrosion. Inspect the probe and cable periodically for physical damage, especially in high-humidity environments (less than 3% ASF change at 93% humidity per IEC 68-2-3).
Compatibility & Integration
This probe is part of the 3300 XL system and is compatible with Bently Nevada 3300 XL extension cables and Proximitor sensors. The standard 5 or 1 meter system achieves an ISF of 7.87 V/mm ± 5% over 0°C to +45°C. For extended temperature ranges, the ETR system maintains ± 6.5% accuracy.
Selection Guide & Purchasing Advice
When selecting a replacement probe, verify the thread size (3/8-24 UNF) and total length (0.5 meter). The 330101-00-08-05-02-05 is available at AutoDCSTech, your trusted source for industrial automation parts. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Availability & Condition at AutoDCSTech
| Part Number | 330101-00-08-05-02-05 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
