Overview
The GE CI868AK01 is an IEC 61850 interface communication module designed for integration with ABB 800xA systems. This exchange unit includes a CI868A communication interface and a TP867 baseplate, providing a reliable solution for industrial automation networks.
Technical Specifications Breakdown
Key parameters for the CI868AK01 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Part Number | CI868AK01 |
| Brand | GE |
| Product Type | Communication Module |
| Product Net Weight | 0.7 kg |
| Product Net Depth / Length | 127.5 mm |
| Product Net Height | 186 mm |
| Product Net Width | 59 mm |
| Country of Origin | Sweden |
| Compatibility | 800xA 6.0.3.3 and 6.1.1, Compact Control Builder 6.0.0-3 and 6.1.1 |
Industry Applications
This module is well-suited for power utilities and industrial plants that rely on IEC 61850 for substation automation. It enables seamless communication between protection relays, meters, and control systems, reducing integration complexity. For example, in a smart grid environment, the CI868AK01 facilitates real-time data exchange, improving operational efficiency and fault response times.
Installation & Setup Guidance
Mount the module on a DIN rail using the TP867 baseplate. Ensure the system runs compatible software versions: 800xA 6.0.3.3 or 6.1.1, and Compact Control Builder 6.0.0-3 or 6.1.1. Connect the CI868A communication interface to the network using standard Ethernet cables. Verify proper grounding and power supply before commissioning.
Maintenance & Reliability
Inspect the module periodically for dust accumulation and ensure ventilation slots are clear. Check cable connections for tightness and signs of wear. The device’s compact design (127.5 x 186 x 59 mm) and lightweight construction (0.7 kg) simplify handling during maintenance.
Compatibility & Integration
The CI868AK01 is designed exclusively for ABB 800xA systems with the specified software versions. It supports IEC 61850 protocol for substation automation, enabling integration with modern intelligent electronic devices (IEDs). The exchange unit includes both the CI868A interface and TP867 baseplate, ensuring a complete solution.
Selection Guide & Purchasing Advice
When selecting this module, verify your system’s software version matches the required compatibility. The CI868AK01 is a replacement unit; if you have an older unit to return, follow the RMA process to avoid extra charges.
Troubleshooting & Common Issues
If communication fails, check that the system software is updated to the compatible versions. Ensure the TP867 baseplate is securely mounted and the CI868A interface is properly seated. Verify network cable integrity and IP configuration. If issues persist, consult the system manual or contact AutoDCSTech support.
Availability & Condition at AutoDCSTech
| Part Number | CI868AK01 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
