GE Fanuc IC200NDR010 VersaMax Nano PLC 10-Point Controller

Technical Specifications Breakdown

Key parameters for the IC200NDR010 are listed below for quick reference:

Industry Applications

For example, in a packaging line, the IC200NDR010 can manage a small conveyor section with sensors and actuators, using its 6 inputs for limit switches and 4 outputs for motor starters. Its support for up to 2048 I/O points allows expansion via remote racks, making it scalable for growing systems. The RS-232 and RS-485 ports enable communication with HMIs or SCADA, providing cost-effective integration.

Installation and Setup Guidance

Mount the module in a clean, dry environment within the 0-55 degrees Celsius ambient temperature range. Use the RS-232 port for initial programming with ladder diagrams or function charts, as supported by the device. The outputs are set to an open state by default, so ensure external loads are within 5 to 30 Volts DC or 5 to 250 Volts AC. The replaceable battery backs up the real-time clock and RAM; install it before powering up to retain program data.

Maintenance and Reliability

Periodically inspect the LED indicators on the front panel—PWR, OK, and RUN—for system status. The module's space-saving design and 1-pound weight simplify handling. Keep the ambient temperature stable to ensure reliable operation. The battery should be replaced every few years to maintain RAM and clock backup.

Compact Control for Space-Constrained Automation

In a recent factory retrofit, an engineer needed to replace a bulky PLC in a tight panel with limited space. The solution was the GE Fanuc IC200NDR010 VersaMax Nano PLC, a 10-point device that packs essential control into a compact, lightweight form factor.

Compatibility and Integration

Its Network Interface Unit (NIU) can scan I/O and communication interfaces, allowing it to function as an I/O station. The two serial ports support RS-232 and RS-485 protocols for high-speed data transmission within local industrial networks. It meets CE standards and is cULus listed.

Selection Guide and Purchasing Advice

When selecting this module, verify its lifecycle status with AutoDCSTech before ordering. The IC200NDR010 is a reliable choice for small to medium automation projects. AutoDCSTech offers this unit along with support and documentation to ensure a smooth integration.
