IC693CPU367: Series 90 30 PROFIBUS DP Slave CPU Module
The IC693CPU367 is the Series 90 30 PROFIBUS DP Slave CPU Module covered on this page. The attribute that decides whether it fits the existing installation without modification is 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit).
The reason to specify this exact variant is series 90 30 profibus dp slave cpu module. A communication or network module is judged by the protocol it carries and the bus it joins, not by its catalogue headline. series 90 30 profibus dp slave cpu module sets which controllers and field devices it can bridge, and the isolation and termination it provides. Matching 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) against the existing network topology avoids a module that fits the rack but cannot talk to the rest of the system.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | IC693CPU367 |
| Series | Series 90-30 |
| Part Number | IC693CPU367 |
| Configuration | Slave |
| Supported Network | PROFIBUS-DP |
| Number of I/O Points | 4096 (discrete) |
| Register Memory | 240 kilobytes |
| Backplane Current Consumption | 940 milliAmps at 5 Volts DC |
| Floating Point Math | Yes |
| Processor Model | 80386EX |
| Serial Port | RS-232 |
| Supported Data Rates | 9.6 / 19.2 / 93.75 / 187.5 / 500 kilobits per second and 1.5 / 3 / 6 / 12 megabits per second |
| CPU Version | 10.72 or later |
| Operating Temperature | 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) |
| Storage Temperature | -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit) |
This part belongs to a discontinued platform (GE Series 90-30), superseded by PACSystems RX3i (IC695 series). We stock remaining new and refurbished units.
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| ge-fanuc-ic693cpu360-series-90-30-cpu-module-25-mhz-processor | confirm the configuration against your installation |
| ge-fanuc-ic693cpu363-series-90-30-cpu-module-overview | confirm the configuration against your installation |
| ge-fanuc-ic693cpu364-series-90-30-cpu-module-with-ethernet | confirm the configuration against your installation |
| ge-fanuc-ic693cpu366-cpu-module-with-profibus-master-for-series-90-30 | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | IC693CPU367 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
