GE IC200ALG328 Versamax Analog Output Module for Industrial Automation

Technical Specifications Breakdown

Key parameters for the IC200ALG328 are listed below for quick reference:

Industry Applications

This analog output module is well-suited for process control environments requiring precise current loop signals. Typical applications include valve positioning, variable frequency drive control, and setpoint adjustment in chemical, oil and gas, and water treatment plants. The 12 single-ended channels allow for efficient multi-point control, while the 250VAC isolation protects against ground loops and electrical noise. The configurable output default ensures safe state behavior during communication loss, reducing downtime and equipment risk.

Installation & Setup Guidance

Mount the module on a DIN rail within a Versamax backplane. Ensure the backplane current consumption does not exceed 550mA at 5V output. The module supports hot insertion when performed carefully to protect rack and module components. An external power supply is required for the output channels to operate properly. Refer to the GE Fanuc manual for detailed wiring and configuration steps.

Maintenance & Reliability

Periodically inspect the module for signs of thermal stress, especially when operating at 30 Volts DC. Thermal derating depends on ambient air temperature and DIN rail position. Keep the enclosure clean and ensure adequate airflow. The diagnostic tools help monitor channel health and detect faults early.

The GE IC200ALG328 Versamax Analog Output Module

Industrial automation systems demand precise and reliable analog output control. The GE IC200ALG328 Versamax I/O module, manufactured by GE Fanuc Automation, provides 12 single-ended analog current-sourcing outputs. This output module operates with a voltage range of 18 to 30 Volts DC and features a 13-bit resolution for accurate signal generation. With an update rate of 15 milliseconds maximum, it delivers responsive performance for demanding applications.

Compatibility & Integration

The IC200ALG328 is compatible with Ethernet, Genius, Profibus, and DeviceNet firmware, as well as PLC CPU firmware and VersaPro software. Channels can be scaled with the IC200ALG326 module due to similar characteristics. This flexibility simplifies integration into existing GE Fanuc systems.

Selection Guide & Purchasing Advice

When selecting an analog output module, consider channel count, resolution, and isolation requirements. The IC200ALG328 offers 12 channels with 13-bit resolution and robust isolation. For lifecycle status and availability, contact AutoDCSTech before ordering. AutoDCSTech provides genuine industrial automation parts with expert support.

Troubleshooting & Common Issues

If outputs do not respond, verify the external power supply and check the backplane current consumption. Use the diagnostic LEDs to identify channel faults. Ensure the module is not in thermal derating condition by confirming ambient temperature and DIN rail orientation. For persistent issues, consult the GE Fanuc documentation.
