Schneider TSXCANCD300 CANopen Cable 300m for Industrial Networks

Technical Specifications Breakdown

Key parameters for the TSXCANCD300 are listed below for quick reference:

Industry Applications and Use Cases

The TSXCANCD300 is engineered for environments where long-distance, reliable CANopen communication is essential. In a typical automotive assembly line, for example, multiple PLCs, drives, and I/O blocks are distributed across hundreds of meters. This cable provides a single, continuous 300-meter trunk line that maintains signal integrity, reducing the need for repeaters or complex network segmentation. Similarly, in material handling systems such as conveyor networks for warehouses or airports, the cable's robust construction minimizes electromagnetic interference, ensuring that position sensors and motor controllers communicate without data loss. The CE marking confirms compliance with European safety and environmental standards, giving engineers confidence in its use within regulated industrial settings.

Installation and Setup Guidance

When deploying the TSXCANCD300, proper routing and strain relief are critical to preserving signal quality. Avoid running the cable parallel to high-voltage power lines or near variable frequency drives to prevent noise coupling. Secure the cable at regular intervals using appropriate cable ties or clamps, ensuring the minimum bend radius is respected as per Schneider guidelines. Since the cable is pre-terminated, verify that the connectors are fully seated and locked into the CANopen bus couplers or devices. For optimal network performance, terminate both ends of the bus with the correct 120-ohm resistors, as specified by the CANopen standard. Always power down the system before making or breaking connections to avoid damage to transceivers.

Maintenance and Reliability

The TSXCANCD300 is designed for long-term reliability in fixed industrial installations. With an IP20 rating, it is suitable for use in clean, dry control cabinets or enclosed cable trays. Periodically inspect the cable for physical damage, such as cuts, kinks, or crushed sections, which can degrade signal quality. Check that connectors remain clean and free from corrosion, especially in environments with high humidity or airborne contaminants. If the cable is exposed to vibration, ensure that all support points are secure. No special maintenance tools or procedures are required beyond standard visual inspection and continuity testing during scheduled plant shutdowns.

Reliable CANopen Bus Connectivity for Demanding Industrial Networks

When building or maintaining a robust CANopen network in an industrial automation environment, the quality of the physical cabling is often an overlooked but critical factor. A single point of failure in the bus cable can bring an entire production line to a halt, causing costly downtime and troubleshooting headaches. The Schneider TSXCANCD300 is purpose-built to address this challenge, providing a , pre-terminated connecting cable designed specifically for CANopen bus systems.

Compatibility and Integration

This accessory is specifically designed for CANopen networks, one of the most widely used fieldbus protocols in industrial automation. It is compatible with Schneider Electric's own CANopen-compatible PLCs, drives, and I/O modules, as well as third-party devices that adhere to the CANopen standard. The 300-meter length supports both master-slave and distributed control topologies, allowing flexible network layouts. When integrating into an existing system, verify that the total bus length (including drop lines) does not exceed the CANopen specification for your chosen baud rate. For most applications, a 125 kbps baud rate supports up to 500 meters, making this cable suitable for the majority of medium-to-large networks.

Selection Guide and Purchasing Advice

Choosing the right CANopen cable is a balance between length, environment, and network requirements. The TSXCANCD300 is an choice when you need a single, long, pre-terminated run for a backbone segment. For shorter connections or device drop lines, consider other Schneider CANopen cable variants. Before ordering, confirm that your network topology and baud rate can accommodate a 300-meter trunk. AutoDCSTech stocks this genuine Schneider accessory, ensuring you receive a factory-tested component that meets all original specifications. Please verify current lifecycle status and availability with AutoDCSTech before ordering to ensure timely delivery for your project.
