Product Overview
When your TSX Micro PLC needs reliable program storage and quick data access, the Schneider TSXMFP032P flash memory card delivers consistent performance. Designed specifically for the TSX Micro PLC series, this 32K16 memory card uses a standard 68-pin PCMCIA interface for straightforward installation. Its compact form factor fits seamlessly into compatible systems, making it a practical choice for industrial automation tasks.
Technical Specifications Breakdown
The TSXMFP032P operates reliably across a temperature range of 0 to 60 °C and can withstand storage extremes from -40 to 85 °C. With humidity tolerance from 5% to 95% non-condensing, it performs well in varying environmental conditions. The card offers shock resistance of 15 g for 11 ms and vibration resistance of 1.5 mm peak to peak from 3 to 13 Hz, and 1 g from 13 to 150 Hz, ensuring durability in demanding industrial settings. It holds CE, UL, and CSA certifications, confirming compliance with industry safety standards. LED indicators provide real-time status monitoring, allowing quick visual checks of operational state.
Industry Applications
In manufacturing environments where PLCs control assembly lines or packaging machinery, the TSXMFP032P provides dependable memory for program storage and data logging. Its wide temperature and humidity tolerance make it suitable for both indoor factory floors and outdoor enclosures. The shock and vibration resistance also supports use in applications with moving equipment or transport systems.
Installation & Setup Guidance
Installing the TSXMFP032P is straightforward: insert the card into the PCMCIA slot of a compatible TSX Micro PLC, such as the TSX P57103M. Ensure the system is powered off before insertion. After power-up, the LED indicators will show the card's status. Verify proper seating of the connector to avoid communication errors.
Maintenance & Reliability
Routine inspection of the card and its connector is recommended to maintain reliable operation. Keep the PCMCIA slot free of dust and debris. The card's robust environmental ratings reduce the need for frequent replacements, contributing to lower total cost of ownership.
Compatibility & Integration
The TSXMFP032P is specifically compatible with the TSX P57103M PLC. Its standard PCMCIA form factor also allows integration with other systems that accept 68-pin PCMCIA cards. For best performance, use only with Schneider TSX Micro PLCs as specified.
Selection Guide & Purchasing Advice
Before purchasing, verify that your PLC model supports PCMCIA flash memory cards. The TSXMFP032P is a direct replacement for original Schneider memory cards. SpareTechPLC stocks this item and can confirm current availability and lifecycle status. Contact our team for assistance with compatibility or ordering.
Frequently Asked Questions
What is the memory capacity of the TSXMFP032P?
The TSXMFP032P has a memory capacity of 32K16.
Which PLC models are compatible with this card?
It is compatible with the TSX P57103M PLC from Schneider Electric's TSX Micro series.
What certifications does the TSXMFP032P hold?
It holds CE, UL, and CSA certifications.
Does the card have status indicators?
Yes, it includes LED indicators for real-time status monitoring.
What is the operating temperature range?
The operating temperature range is 0 to 60 °C.
