Product Introduction
When machinery protection demands precise, non-contact measurement, the Vibro Meter 111-412-000-013-A1-B1-E050-F1-G050-H05 Proximity Measuring System delivers reliable performance. This system uses eddy-current technology to monitor shaft vibration and gap/position without physical contact. Part of the renowned vibro-meter product line, it conforms to API 670 recommendations and is available in Ex certified versions for hazardous areas.
Technical Specifications Breakdown
The 111-412-000-013-A1-B1-E050-F1-G050-H05 offers a frequency response from DC to 20 kHz (−3 dB), ensuring accurate vibration measurement across a wide range. Its measurement range covers 2 or 4 mm, suitable for various shaft sizes. The temperature range spans −40 to +180 °C with drift less than 5%, and short-term survival up to +220 °C. The transducer head and integral cable carry an IP68 protection rating per IEC 60529, making it robust in harsh environments.
Industry Applications
This proximity measuring system excels in shaft relative vibration and gap/position measurement chains for machinery protection and condition monitoring. It integrates seamlessly with VM600Mk2/VM600 and VibroSmart monitoring systems. In API 670 applications, the system provides reliable data for critical rotating equipment, helping prevent unplanned downtime.
Installation & Setup Guidance
Install the transducer with the M10 × 1 thread (body thread B1) into a suitable mounting hole. The integral cable length is 5.0 m ±500 mm (E050), with an additional flexible hose protection (F1) of 5.0 m (G050). Total system length is 5 m (H05). Hand-tighten the self-locking miniature coaxial connectors until locked. Ensure the transducer tip and cable remain clean and undamaged during installation.
Maintenance & Reliability
Inspect the transducer and cable periodically for physical damage. The stainless steel body (AISI 316L) and IP68-rated head resist moisture and debris. The flexible stainless steel hose provides mechanical protection but is not leak-tight. For Ex zone use, verify cable and connector integrity regularly. This system's temperature-compensated design maintains accuracy over time, reducing maintenance needs.
Compatibility & Integration
The 111-412-000-013-A1-B1-E050-F1-G050-H05 requires a high-frequency power source from an IQS900 signal conditioner. It works with VM600Mk2/VM600 and VibroSmart machinery monitoring systems. The voltage or current output includes short-circuit protection. Use with compatible condition monitoring platforms for complete machinery health assessment.
Selection Guide & Purchasing Advice
Before ordering, confirm your system length requirements: this model includes a 5 m integral cable and 5 m flexible hose. Verify the environmental conditions match the −40 to +180 °C transducer range. For hazardous area use, select the Ex certified version. SpareTechPLC stocks this Vibro Meter system and can assist with compatibility questions.
Please verify current lifecycle status and availability with SpareTechPLC before ordering.
