Industry Trends Driving Network Module Adoption
Industrial automation increasingly relies on seamless communication between controllers, sensors, and enterprise systems. The shift toward Industry 4.0 and the Industrial Internet of Things (IIoT) demands robust network modules that can handle multiple protocols and provide reliable data exchange. Engineers need components that support both legacy and modern standards while ensuring uptime in harsh environments.
The Schneider BMXNOC0401 addresses these requirements as part of the Modicon M340 automation platform. It combines EtherNet/IP and Modbus/TCP support in a single module, simplifying integration and reducing network complexity.
Introducing the BMXNOC0401
When you need a dependable Ethernet TCP/IP network module for your Modicon M340 system, the BMXNOC0401 from Schneider Electric offers a proven solution. This module provides four RJ45 ports operating at 10/100 Mbit/s, making it suitable for both new installations and upgrades.
It is designed for transparent ready class B30 networks and includes an embedded 4-port switch with RSTP support and port mirroring. The module is powered internally via the rack, simplifying wiring and reducing external component requirements.
Technical Specifications and Performance
The BMXNOC0401 draws 555 mA at 3.3 V DC, ensuring efficient power usage within the rack. It operates in ambient air temperatures from 32 to 140 °F (0 to 60 °C) and handles relative humidity from 10 to 95 percent without condensation, making it suitable for demanding industrial environments.
With an IP20 degree of protection, it is designed for use in clean, controlled enclosures. The module weighs 0.4 lb (US) (0.2 kg) and carries multiple certifications including CE, UL, CSA, RCM, EAC, and ATEX zone 2/22, ensuring compliance with international standards.
Application Scenarios and Use Cases
In a typical manufacturing line, the BMXNOC0401 connects programmable logic controllers to remote I/O racks and operator interfaces. Its support for both EtherNet/IP and Modbus/TCP I/O scanner and messaging allows it to communicate with a wide range of devices from different vendors.
For process control applications, the module's FDR server and SNMP network administrator features simplify device replacement and network monitoring. The embedded 4-port switch reduces the need for external switches, lowering overall system cost and complexity.
Real-World Application Example
Consider a packaging facility upgrading its control network to support real-time data collection. The BMXNOC0401 integrates into the existing Modicon M340 rack, providing four Ethernet ports for connecting cameras, barcode scanners, and HMIs. Its RSTP support ensures network redundancy, minimizing downtime if a cable fails.
This configuration allows the facility to implement predictive maintenance and track production metrics without major infrastructure changes.
Compatibility and Integration
The BMXNOC0401 is designed specifically for the Modicon M340 automation platform. It supports 10BASE-T and 100BASE-TX Ethernet standards and provides communication services including bandwidth management, data editor via PC terminal, and rack viewer.
It also supports Modbus TCP I/O scanner and messaging, as well as Ethernet/IP I/O scanner and messaging, ensuring broad compatibility with Schneider and third-party devices. The module's CE marking and compliance with directives 2014/35/EU, 2014/30/EU, and 2014/34/EU confirm its suitability for European markets.
Why Choose AutoDCSTech
AutoDCSTech offers the Schneider BMXNOC0401 with reliable availability and fast shipping. Our team understands industrial automation and can help you select the right components for your application.
We stock genuine Schneider parts and provide detailed product information to support your purchasing decision. Contact us for current lifecycle status and availability before ordering.
Frequently Asked Questions About the BMXNOC0401
What protocols does the BMXNOC0401 support?
The BMXNOC0401 supports both EtherNet/IP and Modbus/TCP for I/O scanner and messaging. It also provides bandwidth management, FDR server, SNMP network administrator, and RSTP support.
What is the power requirement for this module?
The module draws 555 mA at 3.3 V DC and is powered internally via the rack. No external power supply is needed.
Is the BMXNOC0401 certified for hazardous locations?
Yes, it carries ATEX zone 2/22 and IECEx zone 2/22 certifications, as well as hazardous location class I division 2. It also meets standards including EN/IEC 61131-2 and UL 61010-2-201.
How many Ethernet ports does the module have?
The BMXNOC0401 includes four RJ45 ports operating at 10/100 Mbit/s. It features an embedded 4-port switch with port mirroring and RSTP support.
What is the operating temperature range?
The module operates in ambient air temperatures from 32 to 140 °F (0 to 60 °C) and can handle relative humidity from 10 to 95 percent without condensation.
Conclusion
The Schneider BMXNOC0401 network module delivers reliable Ethernet connectivity for Modicon M340 systems. Its support for dual protocols, embedded switch, and robust certifications make it a practical choice for modern industrial networks.
For engineers seeking a proven solution with global compliance, the BMXNOC0401 offers the performance and flexibility needed to meet today's automation challenges. Contact AutoDCSTech to learn more or place an order.
