BMXP3420102 Processor Module Guide: Specs and Applications

Understanding the BMXP3420102 Processor Module

Industrial automation systems demand reliable and powerful controllers. The Schneider BMXP3420102 processor module, part of the Modicon M340 automation platform, delivers robust performance for mid-range applications. It supports up to 1024 discrete I/O in a multi-rack configuration and 256 analog I/O, making it suitable for complex control tasks.

This module integrates Modbus and CANopen communication protocols, enabling seamless connectivity with various field devices. Its compact design and IP20 protection make it ideal for cabinet installations in controlled environments.

Technical Specifications and Performance

The BMXP3420102 features an internal RAM of 4096 kB, with 256 kB dedicated to data and 3584 kB for program constants and symbols. It executes Boolean instructions in 0.12 µs and floating-point operations in 1.16 µs, ensuring fast processing for real-time control.

With a current consumption of 90 mA at 24 V DC, the module is powered via the rack. It supports up to 4 racks and 11 slots, providing flexibility for system expansion. The operating temperature range is 32 to 140 °F (0 to 60 °C), and it operates in relative humidity of 10 to 95% without condensation.

Communication and Integration Capabilities

The BMXP3420102 offers multiple integrated connection types, including non-isolated serial links for RS232C and RS485, USB port at 12 Mbit/s, and a CANopen master bus with SUB-D 9 connector. It supports transmission rates from 20 kbit/s to 1 Mbit/s, depending on cable length.

This module can manage up to 63 CANopen server devices and supports network management (NMT), Process Data Object (PDO), and Service Data Object (SDO) services. It also accommodates up to 2 Ethernet communication modules and 4 AS-Interface modules for expanded connectivity.

Application Scenarios in Modern Manufacturing

In a typical packaging line, the BMXP3420102 can control multiple conveyor sections and sorting stations. Its CANopen interface coordinates independent axes, while Modbus links to variable frequency drives and sensors. The processor handles up to 36 application-specific channels, enabling precise motion control.

For water treatment facilities, the module manages analog inputs from flow meters and pH sensors, executing PID loops for chemical dosing. Its 256 analog I/O capacity in multi-rack setups supports extensive monitoring and control requirements.

Real-World Application Example

Consider a material handling system in a distribution center. The BMXP3420102 coordinates 8 conveyor zones using CANopen for motor drives and Modbus for barcode scanners. The processor executes fast task cycles at 0.13 ms overhead, ensuring timely responses to package detection events.

Frequently Asked Questions About the BMXP3420102

What communication protocols does the BMXP3420102 support?

The module supports Modbus RTU/ASCII and CANopen protocols. It includes non-isolated serial links for RS232C and RS485, a USB port, and a CANopen master bus. These interfaces enable integration with a wide range of industrial devices.

What is the maximum I/O capacity of this processor?

In a multi-rack configuration, the BMXP3420102 supports up to 1024 discrete I/O and 256 analog I/O. For single-rack setups, it handles 704 discrete I/O and 66 analog I/O. It also supports up to 36 application-specific channels.

Is the BMXP3420102 certified for safety and compliance?

Yes, the module carries CE, UL, CSA, RCM, and EAC certifications. It complies with EN 61131-2, EN/IEC 61010-2-201, and other standards. It is suitable for hazardous locations Class I Division 2. Please verify current lifecycle status and availability with AutoDCSTech before ordering.

Why Choose AutoDCSTech for Your Automation Needs

AutoDCSTech specializes in industrial automation spare parts, offering genuine Schneider components like the BMXP3420102. Our team provides expert support to help you select the right modules for your system. We ensure reliable sourcing and fast delivery to minimize downtime.
