Evaluating the BMXCPS2000 Power Supply Module
When selecting a power supply for your industrial control system, you need a reliable unit that matches your application's voltage and power demands. The Schneider BMXCPS2000 is a power supply module from the Modicon X80 range, designed to deliver stable power to processors and I/O modules. This buyer's guide helps you assess its key specifications and determine if it fits your setup.
Key Technical Specifications to Consider
The BMXCPS2000 accepts a primary voltage of 100...240 V AC, with a voltage limit of 85...264 V AC. It operates at a network frequency of 50/60 Hz, with limits of 47…63 Hz. The module provides multiple secondary power outputs: 10.8 W for a 24 V DC sensor power supply, 16.8 W for a 24 V DC I/O module and processor power supply, and 8.3 W for a 3.3 V DC I/O module logic power supply.
Input current ratings are 0.31 A at 240 V and 0.61 A at 115 V. The apparent power is 0.07 kVA. Protection features include overload, overvoltage, and short-circuit protection for the secondary circuit, plus an internal fuse for the primary circuit. The module has an IP20 degree of protection and weighs 0.3 kg.
Applications in Industrial Environments
The BMXCPS2000 is suitable for use in manufacturing lines, process control systems, and machine automation where a Modicon X80 backplane is present. Its 24 V DC sensor power supply can power proximity sensors and limit switches, while the 24 V DC I/O module supply supports digital and analog I/O modules. The 3.3 V DC logic supply is dedicated to powering the processor and I/O module logic circuits.
In a typical packaging line application, the BMXCPS2000 supplies power to a Modicon X80 processor and several I/O modules controlling conveyors and actuators. The module's overload and short-circuit protection help prevent damage from wiring faults, reducing unplanned downtime.
Compatibility and Integration
The BMXCPS2000 is part of the Modicon X80 range and is compatible with backplanes except for the BMEXBP..02 series. It connects via a 2-pin connector for the alarm relay and a 5-pin connector for line supply, protective earth, and 24 V DC sensor input. The module includes a RESET push-button for cold restart and status LEDs for rack voltage and sensor voltage.
It complies with directives 2014/35/EU (low voltage), 2014/30/EU (EMC), and 2012/19/EU (WEEE). Certifications include Merchant Navy, CSA, UL, CE, RCM, and EAC. The operating temperature range is 0…60 °C, with storage from -40…85 °C.
Frequently Asked Questions
What is the primary voltage range for the BMXCPS2000?
The primary voltage range is 100...240 V AC, with a limit of 85...264 V AC. It operates at 50/60 Hz frequency.
What secondary power outputs does the BMXCPS2000 provide?
It provides 10.8 W at 24 V DC for sensors, 16.8 W at 24 V DC for I/O modules and processor, and 8.3 W at 3.3 V DC for I/O module logic power.
Is the BMXCPS2000 compatible with all Modicon X80 backplanes?
No, it is not compatible with BMEXBP..02 backplanes. Please verify your backplane model before ordering.
Why Choose AutoDCSTech for Your BMXCPS2000
AutoDCSTech offers genuine Schneider BMXCPS2000 modules with fast shipping and expert support. Our team can help you verify compatibility and answer technical questions. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
