Schneider TSXCANKCDF90TP CANopen SUB-D9 Connector with Line Terminator, IP20

Technical Specifications Breakdown

Key parameters for the TSXCANKCDF90TP are listed below for quick reference:

Industry Applications

This connector is essential for terminating CANopen fieldbus segments in applications such as packaging machinery, material handling systems, and automated assembly lines. The 90° bended design allows for tight installations where space is limited, reducing strain on cables and connectors. By ensuring proper bus termination, it minimizes signal reflections and communication errors, directly improving network reliability and reducing downtime.

Installation & Setup Guidance

When installing the TSXCANKCDF90TP, ensure the CANopen bus is powered down. Connect the female SUB-D9 (elbowed) to the device or cable, and use the male SUB-D9 for daisy-chaining or termination. The IP20 rating means it is suitable for clean, dry environments; avoid exposure to dust or moisture. Always verify that the line terminator is correctly engaged to match the bus topology requirements.

Maintenance & Reliability

Periodically inspect the connector for physical damage or loose connections. The IP20 enclosure does not provide protection against liquids, so keep the area dry. No special maintenance is required beyond standard visual checks during routine system audits.

Robust CANopen Bus Connectivity with the TSXCANKCDF90TP

Industrial automation networks demand reliable physical connections to maintain data integrity and system uptime. The Schneider TSXCANKCDF90TP is a purpose-built CANopen bus connector and line terminator, designed to provide secure and space-saving connections in control cabinets and machinery. This component belongs to the CANopen range and serves as an accessory for CANopen bus systems, ensuring proper termination and signal quality.

Compatibility & Integration

The TSXCANKCDF90TP is designed for CANopen bus systems within the Schneider CANopen range. Ensure that the bus length and node count comply with CANopen standards for optimal performance.

Selection Guide & Purchasing Advice

For reliable CANopen bus termination, choose the TSXCANKCDF90TP. AutoDCSTech offers this genuine Schneider accessory with fast shipping. Verify your system requirements and bus topology before ordering. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
