Introduction
As industrial automation evolves, reliable power delivery becomes critical for system uptime. The Schneider BMXCPS2000 power supply module addresses this need within the Modicon X80 platform, offering a compact solution for distributing clean, regulated power to I/O modules and processors.
Technical Specifications Breakdown
The BMXCPS2000 operates on a primary voltage of 100...240 V AC (85...264 V limit) at 50/60 Hz (47…63 Hz range). It provides three secondary power rails: 10.8 W at 24 V DC for sensor power, 16.8 W at 24 V DC for I/O modules and processor, and 8.3 W at 3.3 V DC for I/O module logic. Input current is 0.31 A at 240 V and 0.61 A at 115 V, with inrush current up to 60 A at 240 V. The module includes overload, overvoltage, and short-circuit protection on the secondary circuit, plus an internal fuse on the primary. It dissipates a maximum of 8.5 W and weighs 0.3 kg.
Industry Applications
In manufacturing lines with Modicon X80 controllers, the BMXCPS2000 ensures stable power for distributed I/O racks. Its multiple voltage outputs support both sensor arrays and logic circuits, making it ideal for packaging, material handling, and process control applications where uptime is paramount.
Installation & Setup Guidance
Mount the BMXCPS2000 on a compatible Modicon X80 backplane (note: not compatible with BMEXBP..02). Connect line supply, protective earth, and 24 V DC sensor input via the 5-pin connector. Use the 2-pin connector for alarm relay output. The RESET push-button allows cold restart. Ensure ambient temperature stays between 0…60 °C and relative humidity 5…95 % at 55 °C without condensation.
Maintenance & Reliability
Regularly inspect the status LEDs: green for rack voltage OK and green for sensor voltage. Verify input voltage stays within 85...264 V AC. The module's IP20 protection suits clean indoor environments. Periodic testing of the alarm relay ensures early fault detection, reducing unplanned downtime.
Compatibility & Integration
The BMXCPS2000 integrates seamlessly with Modicon X80 backplanes and processors. It complies with EN 61131-2, EN 61000-6-4, EN 61000-6-2, and EN 61010-2-201 standards. Certifications include Merchant Navy, CSA, UL, CE, RCM, and EAC. It meets directives 2014/35/EU, 2014/30/EU, and 2012/19/EU.
Selection Guide & Purchasing Advice
Before ordering, confirm your backplane compatibility and total power budget. The BMXCPS2000 delivers 20 W total, so calculate the sum of all connected module loads. SpareTechPLC stocks this module and can advise on current lifecycle status and availability.
Frequently Asked Questions
Q: What is the input voltage range for the BMXCPS2000?
A: The primary voltage range is 100...240 V AC, with an extended limit of 85...264 V AC.
Q: Does the BMXCPS2000 provide sensor power?
A: Yes, it supplies 10.8 W at 24 V DC for sensor power, plus 16.8 W at 24 V DC for I/O modules and processor.
Q: What protection features does this module include?
A: It offers overload, overvoltage, and short-circuit protection on the secondary circuit, plus an internal primary fuse.
Q: What is the weight of the BMXCPS2000?
A: The net weight is 0.3 kg.
Q: Is the BMXCPS2000 compatible with all Modicon X80 backplanes?
A: It is not compatible with BMEXBP..02 backplanes. Check compatibility with your specific backplane model.
