Bently Nevada 330101-00-36-10-01-00 3300 XL 8 mm Probe, 3/8-24 UNF Thread

Technical Specifications Breakdown

Key parameters for the 330101-00-36-10-01-00 are listed below for quick reference:

Industry Applications That Maximize ROI

Turbomachinery Protection

In steam turbines and compressors, the 330101-00-36-10-01-00 monitors shaft radial vibration with a linear range of 2 mm (80 mils). Early detection of increasing vibration trends lets you plan bearing replacements during scheduled outages instead of reacting to catastrophic failures — saving thousands in lost production.

Pump and Motor Condition Monitoring

For critical pumps and electric motors, the probe’s Incremental Scale Factor (ISF) of 7.87 V/mm (200 mV/mil) ± 5% provides consistent, repeatable measurements. This accuracy reduces false alarms and unnecessary maintenance calls, directly lowering your annual maintenance budget.

Generator and Gearbox Reliability

In generators and gearboxes, the robust PPS probe tip and stainless steel case (AISI 303 or 304 SST) withstand harsh environments. The standard probe temperature range of -52°C to +177°C (-62°F to +350°F) ensures reliable operation even in high-temperature zones near bearings.

Installation and Setup Guidance

Mount the 330101-00-36-10-01-00 using the 3/8-24 UNF thread into a properly tapped hole. Ensure the target surface is clean and free of runout. Set the initial gap to the recommended -9 Vdc (approximately 1.27 mm or 50 mils) for radial vibration measurements. Use 3-conductor shielded triad cable (16 to 24 AWG) for field wiring, keeping the maximum length to 305 meters (1,000 feet) between the Proximitor Sensor and monitor to avoid signal roll-off at high frequencies.

Maintenance and Reliability

Inspect the probe cable and connector periodically for signs of wear or damage. The patented CableLoc design provides 330 N (75 lbf) pull strength, but avoid excessive bending at the connector. Keep the probe tip free of debris and oil. The probe’s relative humidity tolerance (less than 3% change in ASF after 56 days at 93% humidity per IEC 68-2-3) ensures stable performance in humid environments.

Cost-Effective Vibration Monitoring with the Bently Nevada 330101-00-36-10-01-00

When unplanned downtime strikes, every minute of lost production cuts into your bottom line. The Bently Nevada 330101-00-36-10-01-00 3300 XL 8 mm Probe offers a proven way to catch bearing wear, shaft misalignment, and imbalance early — before they escalate into costly failures. This non-contact sensor delivers the measurement accuracy you need to schedule maintenance predictively, reducing emergency repairs and extending machinery life.

Compatibility and Integration

This probe is designed for use with Bently Nevada 3300 XL extension cables and Proximitor sensors. The miniature coaxial ClickLoc connector with connector protector provides a secure, quick connection. For systems requiring longer cable runs, the 9-meter system offers an ISF of 7.87 V/mm (200 mV/mil) ± 6.5%.

Selection Guide and Purchasing Advice

When selecting a replacement or new probe, verify the thread type (3/8-24 UNF) and overall length requirements. Contact AutoDCSTech to confirm lifecycle status and availability before ordering. Our team can also assist with Certificate of Origin (COO) if needed.

Please verify current lifecycle status and availability with AutoDCSTech before ordering.
