DS200TBQCG1AAA: Analog Input, Milliamp Input/Output Termination Module
The DS200TBQCG1AAA is the Analog Input, Milliamp Input/Output Termination Module covered on this page. The attribute that decides whether it fits the existing installation without modification is 1 A.
On this unit analog input, milliamp input/output termination module is the figure that decides fit and function. On a rack I/O module the configuration that matters is the one that decides whether the unit drops into the existing slot and speaks the existing signal. analog input, milliamp input/output termination module sets channel count, voltage or current class and isolation behaviour — the three things that decide compatibility with the backplane, the field wiring and the rest of the I/O. Matching 1 A against the rack rather than a generic datasheet avoids a module that installs but does not interface.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | DS200TBQCG1AAA |
| Part Number | DS200TBQCG1A / DS200TBQCG1AAA |
| Series | Mark V |
| Functional Description | RST Analog Termination Board |
| Functional Acronym | TBQC |
| PCB Coating | Normal Coating |
| Functional Revision | 1 A |
| Product Type | Analog Input, Milliamp Input/Output Termination Module |
| Terminal Blocks | 2 (83 terminals each) |
| Jumpers | 15 (BJ1 to BJ17) |
| Connectors | 3 x 40-pin, 3 x 34-pin |
