GE Fanuc IC660BPM500 Genius I/O Battery Pack for Handheld Monitor

Technical Specifications Breakdown

Key parameters for the IC660BPM500 are listed below for quick reference:

Industry Applications for the IC660BPM500

This battery pack is critical for portable HHM use in manufacturing plants, process control facilities, and power generation sites where Genius I/O blocks are deployed. Field engineers rely on the IC660BPM500 to perform device configuration, fault clearing, and I/O forcing without being tethered to AC power. The ability to operate for up to six hours on a full charge supports extended troubleshooting sessions across multiple bus segments.

Installation and Setup Guidance

Upon delivery, the battery pack arrives uncharged. For first-time use, connect the HHM to the battery charger (catalog number IC660BCM501) and allow 24 hours for a full initial charge. Subsequent recharges require only 16 hours. If the pack is new or fully discharged, a minimum 20-minute charge is needed before temporary HHM operation. Always install the battery pack in the HHM even when using AC power to maintain readiness.

Maintenance and Reliability

To maximize service life, allow the IC660BPM500 to fully discharge between charges at least once per month. If the HHM is used predominantly in AC mode for extended periods (over two years), the battery may resist charging and lose independent operation capability. Regularly inspect the battery pack for physical damage and ensure contacts are clean. Store the pack within the recommended temperature range of -40 to 185 degrees Fahrenheit when not in use.

Reliable Power for Genius I/O Handheld Monitoring

The GE Fanuc IC660BPM500 is a dedicated battery pack designed exclusively for the Genius I/O Handheld Monitor (HHM) model IC660HHM501. This 4 lb. unit ensures portable operation for setup, diagnostics, and monitoring of Genius I/O and communication systems. Without a charged battery pack, the HHM cannot function independently, making the IC660BPM500 an essential component for field technicians.

Compatibility and Integration

The IC660BPM500 is purpose-built for the IC660HHM501 handheld monitor and is available in two versions: IC660BPM500A (8-hour charge time) and IC660BPM500B (16-hour charge time). The HHM supports 115 to 230 Volts AC power input, but the battery pack must remain installed for proper operation. A spare battery pack allows alternating use while one charges, minimizing downtime.

Selection Guide and Purchasing Advice

When ordering the IC660BPM500, confirm the required charge time version (A or B) to match your workflow. AutoDCSTech stocks genuine GE Fanuc battery packs to ensure reliable HHM operation. Please verify current lifecycle status and availability with AutoDCSTech before ordering, as this product may be subject to discontinuation.
