IC693MDL931: Output Module
The IC693MDL931 is the Output Module covered on this page. The attribute that decides whether it fits the existing installation without modification is 24 VDC.
What separates this variant from its siblings is output module. On a rack I/O module the configuration that matters is the one that decides whether the unit drops into the existing slot and speaks the existing signal. output module sets channel count, voltage or current class and isolation behaviour — the three things that decide compatibility with the backplane, the field wiring and the rest of the I/O. Matching 24 VDC against the rack rather than a generic datasheet avoids a module that installs but does not interface.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | IC693MDL931 |
| Series | Series 90-30 |
| Part Number | IC693MDL931 |
| Module Type | Output Module |
| Output Type | Relay Outputs |
| Relay Type | Isolated Relay |
| Output Current | 8 Amps per Circuit |
| Rated DC Voltage | 24 VDC |
| Rated AC Voltage | 120/240 VAC |
| Frequency | 50/60 Hz for AC Voltage |
| AC Output Voltage Range | 5-250 VAC |
| DC Output Voltage | 5-30 VDC |
| Maximum Typical Contact Life | 1.1 Million Operations at 5-120 VAC Operating Voltage and 1 Amp of Resistive Current |
This part belongs to a discontinued platform (GE Series 90-30), superseded by PACSystems RX3i (IC695 series). We stock remaining new and refurbished units.
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| ge-ic693mdl930-series-90-30-discrete-output-module-overview | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | IC693MDL931 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
