IC200MDL940: VersaMax 16 Point Relay Output Module
The IC200MDL940 is the VersaMax 16 Point Relay Output Module covered on this page. The attribute that decides whether it fits the existing installation without modification is 0 to 60 degrees Celsius.
The reason to specify this exact variant is versamax 16 point relay output module. On a rack I/O module the configuration that matters is the one that decides whether the unit drops into the existing slot and speaks the existing signal. versamax 16 point relay output module sets channel count, voltage or current class and isolation behaviour — the three things that decide compatibility with the backplane, the field wiring and the rest of the I/O. Matching 0 to 60 degrees Celsius against the rack rather than a generic datasheet avoids a module that installs but does not interface.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | IC200MDL940 |
| Series | VersaMax |
| Part Number | IC200MDL940 |
| Output Type | Relay Output |
| Number of Points | 16 |
| Output Voltage Range | 0 to 125VDC, 0 to 265VAC (47 to 63Hz) |
| Nominal Output Voltage | 5/24/125VDC, 120/240VAC |
| Contact Current Rating | 2.0A max (resistive) |
| Minimum Load Current | 10 mA |
| Output Response Time | 10 ms max |
| Switching Frequency | 20 cycles per minute |
| Backplane Current Draw | 490 mA max |
| Isolation | 250VAC continuous, 1500VAC for 60 sec |
| Operating Temperature | 0 to 60 degrees Celsius |
| Contact Type | Silver alloy |
| Relay Type | Fixed coil, moving armature. |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| ge-ic200mdl930-versamax-8-point-relay-output-module-overview | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | IC200MDL940 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
