IC693MDL653: Series 90 30 24 VDC Discrete Input Module
The IC693MDL653 is the Series 90 30 24 VDC Discrete Input Module covered on this page. The attribute that decides whether it fits the existing installation without modification is 19.2 - 28.8 VDC.
On this unit series 90 30 24 vdc discrete input module is the figure that decides fit and function. On a rack I/O module the configuration that matters is the one that decides whether the unit drops into the existing slot and speaks the existing signal. series 90 30 24 vdc discrete input module sets channel count, voltage or current class and isolation behaviour — the three things that decide compatibility with the backplane, the field wiring and the rest of the I/O. Matching 19.2 - 28.8 VDC against the rack rather than a generic datasheet avoids a module that installs but does not interface.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | IC693MDL653 |
| Series | Series 90-30 |
| Part Number | IC693MDL653 |
| Product Description | Discrete input module |
| Input Voltage Range | 19.2 - 28.8 VDC |
| Nominal Input Voltage | 24 VDC |
| Input Current | 7.5 mA at rated voltage |
| Number of Channels | 32 |
| On-state Voltage | 15 VDC minimum |
| Off-state Voltage | 6 VDC maximum |
| On-state Current | 4.5 mA minimum |
| Off-state Current | 2 mA maximum |
| On Response Time | 2 ms maximum |
| Off Response Time | 2 ms maximum |
| Isolation | 1500 VAC between field side and logic side |
| Backplane Current Draw | 5 mA @ 5VDC |
| Product Lifecycle Status | Discontinued/Obsolete |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| ge-ic693mdl655-series-90-30-discrete-input-module-overview | confirm the configuration against your installation |
| ge-fanuc-ic693mdl652-16-point-discrete-input-module-for-series-90-30 | confirm the configuration against your installation |
| ge-fanuc-ic693mdl654-5-12-vdc-ttl-positive-or-negative-logic-module | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | IC693MDL653 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
