IC693MDL654: 5/12 VDC TTL Positive or Negative Logic Module
The IC693MDL654 is the 5/12 VDC TTL Positive or Negative Logic Module covered on this page. The attribute that decides whether it fits the existing installation without modification is 5 to 12 volts DC, Positive or Negative Logic.
The reason to specify this exact variant is 5/12 vdc ttl positive or negative logic module. Selecting this unit comes down to confirming the configuration against the installation it is being fitted to. 5/12 vdc ttl positive or negative logic module is the attribute that decides fit and function, and verifying 5 to 12 volts DC, Positive or Negative Logic against the existing equipment is the check that prevents a part that installs but does not perform.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | IC693MDL654 |
| Series | Series 90-30 |
| Part Number | IC693MDL654 |
| Rated Voltage | 5 to 12 volts DC, Positive or Negative Logic |
| Input Voltage Range | 0 to 15 volts DC |
| Inputs per Module | 32 (four groups of eight inputs each) |
| Isolation | 1500 Volts between field side and logic side 250 volts between groups |
| Input Current | 3.0 mA (typical ON current @ 5 VDC) 8.5 mA (typical ON current @ 12 VDC) |
| On-state Voltage | 4.2 to 15 Volts DC |
| Off-state Voltage | 0 to 2.6 Volts DC |
| On-state Current | 2.5 mA (minimum) |
| Off-state Current | 1.2 mA (maximum) |
This part belongs to a discontinued platform (GE Series 90-30), superseded by PACSystems RX3i (IC695 series). We stock remaining new and refurbished units.
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| ge-ic693mdl655-series-90-30-discrete-input-module-overview | confirm the configuration against your installation |
| ge-fanuc-ic693mdl652-16-point-discrete-input-module-for-series-90-30 | confirm the configuration against your installation |
| ge-ic693mdl653-series-90-30-24-vdc-discrete-input-module | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | IC693MDL654 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
