IC693TCM302: Series 90 30 Temperature Control Module
The IC693TCM302 is the Series 90 30 Temperature Control Module covered on this page. The attribute that decides whether it fits the existing installation without modification is 0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit).
What separates this variant from its siblings is series 90 30 temperature control module. Selecting this unit comes down to confirming the configuration against the installation it is being fitted to. series 90 30 temperature control module is the attribute that decides fit and function, and verifying 0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit) against the existing equipment is the check that prevents a part that installs but does not perform.
| Feature | Specification |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Brand | GE |
| Part Number | IC693TCM302 |
| Series | Series 90-30 |
| Part Number | IC693TCM302 |
| Output Voltage Range | 18 to 30 Volts DC |
| External Power Supply | 18 to 36 Volts DC (2.5 Amps inrush) |
| Off-State Leakage (Maximum) | 0.1 milliAmps |
| Load Current | 100 milliAmps |
| Internal Power Used | 150 milliAmps at 5 Volts DC |
| Number of Channels | 8 input / 8 output |
| Overload Threshold Current | 700 milliAmps typical, 2 milliseconds minimum |
| Thermocouple Impedance | 30 Ohms (maximum) |
| Operating Temperature | 0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit) |
| Storage Temperature | -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit) |
| Product Lifecycle Status | Discontinued/Obsolete |
Related Configurations
Other published configurations in the same family — confirm the distinguishing specification against your installation:
| Related Part Number | Configuration Difference |
|---|---|
| ge-fanuc-ic693tcm303-temperature-control-module-for-series-90-30 | confirm the configuration against your installation |
Availability & Condition at AutoDCSTech
| Part Number | IC693TCM302 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
