Introduction to the 3500/94M-02-00-00 VGA Display Module
This VGA Display Module is built for 19-inch rack mounting and features a 10-inch LCD with LED backlight. It is part of the 3500 series, engineered to provide real-time status, data, and values from your monitoring network.
The module is designed for industrial use, with an operating temperature range of -20°C to 65°C (-4°F to 149°F) and humidity tolerance of 10% to 85% RH non-condensing. This makes it suitable for demanding environments where reliable display is critical.
Key Features and Technical Specifications
The 3500/94M-02-00-00 comes with a set of features that enhance its usability and integration. Its compact dimensions (387.4 mm x 248.9 mm x 49.0 mm) and panel cutout of 342.9 mm x 228.6 mm allow for flexible mounting options, including face mount, 19-inch rack mount, panel mount, or independent mount.
- Display: 10-inch diagonal LCD with LED backlight, industrial hardened.
- Power: 24 Vdc power supply included, permissible voltage range 10 Vdc to 28 Vdc.
- Inrush Current: 3.5 A @ 24 V (< 500 µs).
- Operating Current: < 500 mA.
- Touch Interface: GFG Resistive Touch Screen.
- Environmental Limits: Operating temperature -20°C to 65°C, humidity 10% to 85% RH non-condensing.
- Agency Approvals: CE, UL, CUL; designed for IP54; Class I, Div 2; ATEX/IECEx.
These specifications ensure that the module can handle the rigors of continuous operation while providing a clear interface for operators.
Applications and Use Cases
The 3500/94M-02-00-00 is ideal for use in turbine, compressor, and other rotating machinery monitoring systems. Its rugged design and wide temperature range make it suitable for installation in control rooms or field enclosures. For instance, in a power generation plant, this display module can show vibration data and alarm statuses, allowing operators to respond quickly to anomalies. Additionally, its Class I, Div 2 approval means it can be placed in certain hazardous areas, reducing the need for expensive purged enclosures and thereby lowering installation costs.
Installation and Setup
Installing the 3500/94M-02-00-00 is straightforward. The module fits into a standard 19-inch rack, requiring one full-height front slot for the monitor module and one full-height rear slot for the I/O module. Ensure that the power supply is within the permissible voltage range (10-28 Vdc) to avoid damage. The touch screen interface is resistive, so calibration may be needed after installation. Refer to the user manual for detailed wiring and configuration steps.
Maintenance and Reliability
To ensure long-term reliability, periodically inspect the display for any signs of physical damage or screen burn-in. Keep the ventilation areas clear of dust and debris to maintain proper cooling. The LED backlight has a long lifespan, but if the display dims over time, it may indicate the need for backlight replacement. Regular inspection per the manufacturer's safety manual is recommended. By maintaining the module, you can avoid costly downtime and extend the service life of your monitoring system.
Compatibility and Integration
The 3500/94M-02-00-00 requires the 3500/22 Transient Data Interface (TDI) module for operation. It also requires specific firmware and software versions, including 3500/94M Firmware 4.06 Rev. C, 3500/22 Firmware Rev 1.71, and corresponding versions of 3500/01, 3500/02, and 3500/03 software. This ensures seamless integration with your existing Bently Nevada monitoring system.
Product Support and Availability
The 3500/94M-02-00-00 is available from AutoDCSTech. Please verify current lifecycle status and availability with AutoDCSTech before ordering. Our team can provide technical support and ensure you receive the right module for your application.
Availability & Condition at AutoDCSTech
| Part Number | 3500/94M-02-00-00 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
