Technical Specifications Breakdown
Key parameters for the 330102-00-20-10-02-05 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Product Type | 3300 XL 8 mm Proximity Probe |
| Unthreaded Length Option | 00 = 0 in |
| Overall Case Length Option | 20 = 2 in |
| Total Length Option | 10 = 1.0 meter (3.3 feet) |
| Connector Type | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval Option | 05 = CSA, ATEX, IECEx Approvals |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Linear Range | 2 mm (80 mils), from 0.25 to 2.3 mm (10 to 90 mils) |
| Recommended Gap Setting for Radial Vibration | -9 Vdc [approximately 1.27 mm (50 mils)] |
| Probe Temperature Range (Standard) | -52°C to +177°C (-62°F to +350°F) |
| Probe Weight | 323 g/m (11.4 oz) |
| Probe Case Thread | 3/8-24 UNF |
Industry Applications for Reliable Shaft Monitoring
The 2 mm linear range and -9 Vdc recommended gap setting allow precise measurement of shaft displacement. With CSA, ATEX, and IECEx approvals, the 330102-00-20-10-02-05 is suitable for hazardous area installations, reducing the risk of unplanned downtime.
Installation and Setup Guidance
When installing the probe, ensure the 3/8-24 UNF thread engages properly with a maximum thread engagement of 0.563 in. Field wiring should use 0.2 to 1.5 mm² (16 to 24 AWG) three-conductor shielded triad cable, with a maximum length of 305 meters (1,000 feet) between the Proximitor sensor and monitor. Set the gap to approximately -9 Vdc (1.27 mm) for radial vibration measurements. Always follow the manufacturer's guidelines for safe installation.
Maintenance and Reliability
The probe's PPS tip and stainless steel case provide durability in demanding environments. The standard temperature range of -52°C to +177°C ensures reliable operation in most industrial settings. Exposing the probe to temperatures below -34°C (-30°F) may cause premature failure of the pressure seal, so avoid such conditions. Regular inspection of the probe and cable for physical damage is recommended.
Precision Vibration Monitoring with the Bently Nevada 330102-00-20-10-02-05
Industrial rotating machinery demands continuous, accurate vibration monitoring to prevent catastrophic failures. The Bently Nevada 330102-00-20-10-02-05 is a 3300 XL 8 mm proximity probe designed for reliable shaft displacement and vibration measurement in harsh environments. This probe delivers the precision needed for predictive maintenance and machine protection.
Compatibility and Integration
This probe is designed for use with Bently Nevada 3300 XL Proximitor sensors. The 1.0 meter cable with miniature coaxial ClickLoc connector simplifies installation. For 5-meter probes, use the 5 meter Proximitor sensor only; for 3-meter probes (available on 330101 models), use the 9 meter Proximitor sensor. The probe's nominal DC resistance (RPROBE) is 7.59 ± 0.50 ohms for the 1.0 m length.
Selection Guide and Purchasing Advice
When selecting a proximity probe, consider the cable length, connector type, and agency approvals. The 330102-00-20-10-02-05 offers a 1.0 meter cable with ClickLoc connector and CSA/ATEX/IECEx approvals, making it a versatile choice for many applications. For lifecycle status and availability, please verify with AutoDCSTech before ordering. AutoDCSTech stocks this model to support your maintenance needs.
Availability & Condition at AutoDCSTech
| Part Number | 330102-00-20-10-02-05 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
