When your industrial machinery demands precise control and reliable power conversion, can you afford to compromise on drive performance? The KEB 13F5A3D-YA0H delivers a robust solution within the F5 Combivert Axis Drive Series, engineered to handle heavy-duty applications with ease.
Product Overview
The KEB 13F5A3D-YA0H is a versatile axis drive designed for demanding industrial environments. Part of the F5 Combivert series, this inverter provides efficient power management for complex machinery. It operates with an input voltage of 400V and an input AC phase of AC 3 PH 50/60Hz, making it suitable for global power standards. With an input current of 16.8A and a UL-rated input current of 15.4A, it ensures stable energy consumption. The drive delivers an output power of 8.3 kVA and an output current of 12A (UL-rated 11A), supporting consistent performance for connected equipment.
Technical Specifications Breakdown
Understanding key parameters helps you match this drive to your application. The input voltage of 400V and UL input voltage of 480V provide flexibility for different electrical systems. The input current of 16.8A (UL 15.4A) indicates the drive's capacity to handle moderate power loads. Output frequency reaches up to 0.599Hz, suitable for low-speed motor control. The output voltage value is 0.Uin, meaning it can match the input voltage level. These specs make the 13F5A3D-YA0H ideal for applications requiring precise low-frequency operation.
Industry Applications
The KEB 13F5A3D-YA0H excels in woodworking and industrial automation. It is specifically compatible with HOLZMA beam saw models such as HPL380, HPP350, and 180. These saws require accurate speed control and dependable power conversion to maintain cut quality and reduce downtime. The drive's 8.3 kVA apparent power output ensures steady electricity supply, even under variable loads. By integrating this inverter, manufacturers can enhance machine longevity and operational efficiency.
Installation & Setup Guidance
Proper installation ensures optimal performance and safety. Mount the drive in a clean, dry environment with adequate ventilation. Verify that the input voltage matches your facility's supply (400V AC three-phase). Connect the input and output phases according to the wiring diagram, respecting the AC 3 PH configuration. The drive supports a frequency range up to 0.599Hz, so configure the control parameters accordingly. Always follow local electrical codes and use appropriate fusing or circuit breakers.
Maintenance & Reliability
Regular maintenance extends the life of your KEB drive. Inspect the unit periodically for dust accumulation, loose connections, or signs of overheating. Ensure cooling fans operate freely. The robust design withstands heavy use in industrial settings, but routine checks prevent unexpected failures. Given its compatibility with HOLZMA saws, schedule inspections during planned maintenance windows to minimize production interruptions.
Compatibility & Integration
The 13F5A3D-YA0H integrates seamlessly into existing automation systems. It is designed for three-phase AC input and output, making it compatible with standard industrial power networks. The drive's flexible voltage and frequency adjustments allow it to work with various motor types. While specific communication protocols are not listed in the provided data, its F5 Combivert series design ensures straightforward integration with compatible controllers and machinery.
Selection Guide & Purchasing Advice
Before purchasing, verify that the drive's specifications match your application requirements. Confirm the input voltage (400V) and phase (AC 3 PH 50/60Hz) align with your power supply. Check the output current (12A) and power (8.3 kVA) against your motor's demands. The Homag part number 4.008.39.1905 provides cross-reference compatibility. For current availability and lifecycle status, contact SpareTechPLC, a reliable supplier of industrial automation parts. We ship internationally to support your operations worldwide.
Frequently Asked Questions
Q: What is the input voltage requirement for the KEB 13F5A3D-YA0H?
A: The drive requires an input voltage of 400V AC three-phase at 50/60 Hz. It also supports a UL-rated input voltage of 480V.
Q: Can this drive control a HOLZMA beam saw?
A: Yes, the 13F5A3D-YA0H is designed for compatibility with HOLZMA models HPL380, HPP350, and 180, providing accurate speed and torque control.
Q: What is the output power rating?
A: The drive delivers an output power of 8.3 kVA apparent power, with an output current of 12A (UL-rated 11A).
Q: Is the output frequency adjustable?
A: Yes, the output frequency can be set up to 0.599Hz, suitable for low-speed applications.
Q: How do I verify compatibility before ordering?
A: Check your system's input voltage, phase, and current requirements against the specs: 400V input, 16.8A input current, and 12A output current. Contact SpareTechPLC for cross-reference assistance.
