Technical Specifications Breakdown
Key parameters for the E82EV152K4C are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Lenze |
| Product Series | 8200 |
| Product Type | Frequency Inverter (Base Controller) |
| Mains Voltage Range | 320-550V AC |
| Alternative DC Supply | 450-775V DC |
| Rated Mains Voltage | 400V AC |
| Frequency | 45/65 Hz |
| Rated Typical Motor Power | 1.5 kW |
| Vector Control | Supported |
| Protection Class | IP20 |
| Ambient Operating Temperature | -10°C to +55°C |
| Ambient Storage Temperature | -25°C to +60°C |
Lenze E82EV152K4C 8200 Vector Drive – Reliable Motor Control for Industrial Applications
The Lenze E82EV152K4C frequency inverter is built to keep your motors running smoothly and efficiently. As part of the proven 8200 series, this base controller delivers dependable variable-speed performance for a wide range of industrial machinery. Whether you are retrofitting an existing system or specifying a new one, this drive offers the precision and robustness you need.
Installation and Setup Guidance
When installing the E82EV152K4C, always follow the manufacturer's manual and local electrical codes. Ensure the mains supply is within the specified range (320-550V AC) and that the motor is correctly connected. Use the recommended fuse ratings: M10 A (VDE) or 10 A (UL), and a B10 A circuit breaker (VDE). The recommended cable cross-section is 1.5 mm² (AWG 16). Always verify the DC bus voltage if using an alternative DC supply (450-775V DC). Proper grounding and shielding are critical to minimize electromagnetic interference.
Built for Reliability and Easy Service
From a maintenance engineer's perspective, the Lenze 8200 series is known for its straightforward installation and serviceability. The IP20 protection class means the drive is suitable for indoor use in control cabinets, protecting against solid objects larger than 12 mm. The operating temperature range of -10°C to +55°C allows installation in most industrial environments without additional cooling, provided the cabinet is adequately ventilated.
Maintenance and Reliability
Regular inspection of the drive is recommended to ensure long-term reliability. Check for dust accumulation on the heatsink and fans (if any), and ensure the ambient temperature stays within the specified range. The drive is designed for continuous operation, but if the internal temperature exceeds limits, the drive will protect itself. There are no user-serviceable parts inside; any maintenance should be performed by qualified personnel.
Designed for Demanding Motor Control
The E82EV152K4C is engineered to handle a wide mains voltage range of 320-550V AC, making it suitable for installations with fluctuating supply conditions. The integrated vector control capability ensures precise speed and torque regulation, which is essential for processes.
Compatibility and Integration
The E82EV152K4C is part of the Lenze 8200 series, which offers a range of options for communication and I/O expansion. While the base controller provides essential functions, you can integrate it into a larger automation system using Lenze's standard interfaces. For specific compatibility details, consult the product documentation or contact AutoDCSTech.
Selection Guide and Purchasing Advice
When selecting a frequency inverter, consider the motor power, voltage range, and environmental conditions. The E82EV152K4C is a solid choice for 1.5 kW motors in a 400V AC system. At AutoDCSTech, we stock a wide range of industrial automation parts, including this Lenze drive. Contact our team to verify current lifecycle status and availability before ordering. We are here to help you keep your operations running.
Availability & Condition at AutoDCSTech
| Part Number | E82EV152K4C |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | Germany |
