Technical Specifications Breakdown
Key parameters for the ABFS16H200 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Type | Connecting Cable |
| Product Line | Modicon Quantum |
| Part Number | ABFS16H200 |
| Connector Type | HE-16 |
| Cable Length | 2 meters |
| Signal Type | Analog I/O |
| Number of Conductors | 16 conductors |
| AWG Gauge | AWG 22 |
| Current Rating | 2A |
| Voltage Rating | 250 V |
| Operating Temperature Range | -20 °C to +60 °C |
| Humidity Tolerance | 95% relative humidity, non-condensing |
| Insulation Material | PVC |
| Cable Construction | Multi-conductor shielded cable |
| Connector Pitch | 5 mm |
| Compliance | RoHS compliant |
| Mounting | Plug-and-play |
Industry Applications
Its shielded construction minimizes electromagnetic interference, ensuring accurate signal transmission in electrically noisy environments. The 2-meter length suits cabinet-to-field device connections, reducing excess cable slack.
Installation & Setup Guidance
For reliable installation, ensure the HE-16 connector is fully seated and locked. Route the cable away from high-voltage power lines to maintain signal integrity. The plug-and-play design eliminates the need for special tools, allowing quick connection to compatible Quantum I/O modules. Verify polarity before finalizing connections.
Maintenance & Reliability
Inspect the cable periodically for physical damage, especially near connectors. The PVC insulation resists moisture and chemicals common in industrial settings. Operate within the -20 °C to +60 °C range to maintain flexibility and performance. The 95% humidity tolerance supports use in damp environments without condensation concerns.
Reliable Signal Transmission with the ABFS16H200
From a maintenance engineer's perspective, the Schneider ABFS16H200 connecting cable offers a straightforward solution for analog I/O signal transmission in Modicon Quantum systems. This 2-meter cable reduces installation complexity with its plug-and-play design, minimizing downtime during setup or replacement. Its robust construction ensures consistent performance in demanding industrial environments.
Selection Guide & Purchasing Advice
When selecting a replacement cable, confirm compatibility with your Quantum I/O module's connector type. The ABFS16H200 is available now at AutoDCSTech. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Availability & Condition at AutoDCSTech
| Part Number | ABFS16H200 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
