Schneider Modicon TSX1702028 Programmable Controller - 24 I/O Relay Output

Technical Specifications Breakdown

Key parameters for the TSX1702028 are listed below for quick reference:

Industry Applications Driving ROI

Packaging Line Control

In high-speed packaging, the controller’s 24 I/O points manage sensors and actuators directly, eliminating costly expansion modules. The relay outputs handle inductive loads like solenoids and small motors without additional interfacing, reducing component costs by up to 20%.

Material Handling Systems

For conveyor sorting and palletizing, the 24 Volts DC inputs interface with proximity sensors and limit switches. The wide supply voltage range (96 to 264 Volts AC) ensures stable operation even in facilities with fluctuating power, preventing costly downtime.

HVAC Building Automation

With an operating temperature range of 5 to 55°C and humidity tolerance up to 95%, this controller performs reliably in unconditioned spaces. The 5 LED indicators enable rapid fault diagnosis, minimizing service call expenses.

Installation & Setup Guidance

Mount the controller in a clean, dry enclosure away from direct heat sources. Connect the power supply within the 110 to 240 Volts AC range, ensuring the frequency matches the local grid (50 or 60 Hertz). Wire 24 Volts DC inputs to compatible sensors, and use relay outputs for loads up to the rated contact capacity. Verify all connections before applying power. The 5 LED indicators provide immediate feedback on power, run, and I/O status.

Maintenance & Reliability

Inspect the controller quarterly for dust accumulation and loose connections. Keep ambient temperature below 55°C and humidity below 95% to avoid condensation. The relay outputs have a finite mechanical life; plan for periodic replacement based on switching cycles. Storage between -25°C and 70°C preserves component integrity.

Optimize Your Automation Budget with the Schneider TSX1702028

Industrial automation projects demand controllers that balance performance with cost efficiency. The Schneider Electric Modicon TSX1702028 programmable controller delivers exactly that—a reliable, 24-input/output solution designed to minimize total cost of ownership while maximizing uptime. By integrating 24 Volts DC inputs and relay outputs, this module reduces external component needs, lowering both initial investment and long-term maintenance expenses.

Compatibility & Integration

Its 24 I/O count and relay outputs make it a direct replacement for older controllers, simplifying upgrades without rewiring.

Selection Guide & Purchasing Advice

When selecting a programmable controller, match I/O count and output type to your application. The TSX1702028 suits medium-complexity tasks where relay isolation is beneficial. AutoDCSTech stocks this model and can advise on lifecycle status. Please verify current lifecycle status and availability with AutoDCSTech before ordering.

Troubleshooting & Common Issues

If the controller fails to power on, check the supply voltage (96 to 264 Volts AC) and frequency (47 to 63 Hertz). If an output does not energize, inspect the relay contact and load wiring. Use the 5 LED indicators to isolate faults: a steady power LED indicates correct supply, while a blinking run LED suggests a program error. For persistent issues, consult the Modicon user manual.
