Schneider Modicon TSXP47425 Controller 24V DC 1.2A 15W

Technical Specifications Breakdown

Key parameters for the TSXP47425 are listed below for quick reference:

Industry Applications

Manufacturing Line Control

With 256 digital and 128 analog I/O points, the controller manages complex machinery sequences and sensor feedback in production lines. The 1 ms per 1K program scan time ensures rapid logic execution, minimizing cycle delays.

Building Automation Systems

Its support for Modbus, Ethernet, CANopen, and Profibus DP allows seamless integration with HVAC, lighting, and access control subsystems. The battery-backed real-time clock enables precise scheduling and time-stamped event logging.

Process Monitoring

Four expansion slots let you add analog input modules for temperature, pressure, or flow monitoring. The 128KB data memory stores historical trends for analysis, aiding predictive maintenance.

Installation & Setup Guidance

Mount the controller on a standard DIN rail within an IP20-rated enclosure. Connect a 24V DC power supply within the 20V to 30V DC input range. Use shielded twisted-pair cables for Modbus and Profibus DP to minimize electromagnetic interference. Configure communication parameters via the integrated Ethernet port using Schneider Electric's software. Ensure adequate airflow around the unit to stay within the -10°C to +60°C operating range.

Maintenance & Reliability

Periodically inspect the DIN rail mounting and tighten connections. Clean the enclosure vents to prevent dust buildup. Verify the battery-backed real-time clock retains time during power outages; replace the battery every 3-5 years as part of routine maintenance. Monitor the power supply voltage to stay within the 20V to 30V DC range.

Reliable Control for Harsh Environments

The Schneider Electric TSXP47425 is a Modicon series controller engineered for precise operations in demanding industrial settings. This unit operates at a rated voltage of 24V DC and draws a rated current of 1.2 A, consuming just 15 watts of power. Its robust design supports an operating temperature range of -10°C to +60°C and a storage temperature range of -25°C to +70°C, ensuring consistent performance across varied conditions. With an IP20 degree of protection, the controller is well-suited for clean, dry environments like control cabinets.

Compatibility & Integration

The controller communicates via Modbus, Ethernet, CANopen, and Profibus DP, making it compatible with Schneider Electric's Modicon ecosystem and third-party PLCs, drives, and HMIs. The 1MB program memory supports large control programs, and the 128KB data memory stores recipes or production logs. Use the four expansion slots for additional I/O modules or specialty cards.

Selection Guide & Purchasing Advice

When selecting the TSXP47425, verify your application's I/O count stays within 256 digital and 128 analog points. Ensure the environment meets IP20 protection and the temperature range. For projects requiring fast program execution, the 1 ms per 1K scan time is ideal. AutoDCSTech stocks this controller and can advise on compatible expansion modules. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
