Technical Specifications Breakdown
Key parameters for the TSX07211622 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Type | Programmable Logic Controller |
| Product Line | TSX Micro PLCs |
| Part Number | TSX07211622 |
| Power Supply Voltage | 24 VDC (nominal) |
| Input Current per Channel | 13 mA @ 24 VDC (sinking/sourcing compatibility) |
| Output Current Capacity | 2 A per channel (resistive/inductive load support) |
| Output Voltage Range | 240 VAC / 30 VDC (dual-rated for AC/DC applications) |
| Output Type | Relay-based switching (electromechanical contacts) |
| Mounting Configuration | Compact brick-style housing (fixed DIN rail mounting) |
| Input Voltage Tolerance | 24 VDC ±10% (stable operation within range) |
| Output Contact Configuration | Form-C (SPDT) relay contacts |
| Application Suitability | Material handling, packaging, textile machinery |
Industry Applications
Material Handling Systems
In conveyor sorting and palletizing lines, the TSX07211622’s relay outputs provide reliable switching for motor contactors and solenoid valves. The dual-rated output voltage (240 VAC / 30 VDC) allows direct control of both AC-powered drives and DC actuators without additional interface relays, reducing panel space and wiring complexity.
Packaging Machinery
For high-speed packaging equipment, the controller’s 2 A per channel capacity handles inductive loads from wrappers and sealers. The Form-C contact configuration enables both normally-open and normally-closed wiring, simplifying fail-safe logic implementation.
Textile Machinery
In textile manufacturing, the 24 VDC nominal supply with ±10% tolerance ensures stable operation despite line fluctuations common in factory environments. The compact brick-style housing mounts easily on DIN rails inside crowded control cabinets.
Installation & Setup Guidance
Mount the TSX07211622 on a standard 35 mm DIN rail using the integrated clip. Ensure the ambient temperature stays within the controller’s operating range (verify in datasheet). Connect the 24 VDC power supply to the designated terminals, observing polarity. For output wiring, use appropriate gauge wire rated for the load current. Configure sinking or sourcing input wiring per your sensor requirements. Always follow local electrical codes and Schneider Electric’s installation manual.
Maintenance & Reliability
Inspect relay contacts periodically for wear, especially in high-cycle applications. Keep the enclosure clean and free of dust to prevent overheating. Verify that the input voltage remains within 24 VDC ±10% to avoid erratic operation. No routine calibration is required for this electromechanical relay-based controller.
Compatibility & Integration
Its relay outputs are compatible with most industrial loads, including contactors, relays, and indicator lamps. For communication, use the built-in serial port (if present) or add a communication module from the TSX Micro series.
Selection Guide & Purchasing Advice
When selecting the TSX07211622, confirm that your application’s load current per channel does not exceed 2 A and that the output voltage matches your equipment (240 VAC or 30 VDC). For mixed AC/DC loads, this controller eliminates the need for separate output modules. AutoDCSTech stocks this model and can advise on availability and lifecycle status. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Availability & Condition at AutoDCSTech
| Part Number | TSX07211622 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
