Schneider TSXCANCBDD1 CANopen Cordset – 1m Molded SUB-D9 Connector

Technical Specifications Breakdown

Key parameters for the TSXCANCBDD1 are listed below for quick reference:

Industry Applications and Cost Benefits

The 1-meter length reduces excess cable waste, directly lowering material costs. The molded connectors eliminate field-wiring errors, cutting installation labor time by up to 30% compared to traditional screw-terminal connections. UL certification ensures compliance with North American safety standards, avoiding costly retrofit expenses.

Installation and Setup Guidance

Mount the cordset by aligning the female SUB-D9 connectors with the male ports on your CANopen devices. Hand-tighten the locking screws to secure the connection—do not over-torque. Route the cable away from high-voltage power lines to prevent electromagnetic interference. The IP20 rating is suitable for clean, dry control cabinets; avoid exposure to moisture or dust. No special tools are required.

Maintenance and Reliability

Periodically inspect the connectors for signs of wear or corrosion. Clean contacts with a dry cloth if needed—do not use solvents. The molded design provides strain relief, extending service life. In high-vibration environments, verify that locking screws remain tight. This cordset is a passive component with no moving parts, offering high reliability and low total cost of ownership.

Cost-Effective CANopen Connectivity with the TSXCANCBDD1

Industrial automation networks demand reliable, cost-effective connections to minimize downtime and operational expenses. The Schneider TSXCANCBDD1 CANopen cordset delivers a robust, standardized interface for your CANopen bus systems, reducing installation complexity and long-term maintenance costs. This molded female SUB-D9 cordset provides a secure, IP20-rated connection that ensures signal integrity and reduces the risk of communication failures.

Compatibility and Integration

The TSXCANCBDD1 is designed for Schneider CANopen systems and is compatible with any standard CANopen device using SUB-D9 connectors. It supports all CANopen baud rates and protocols. Confirm device compatibility by checking your equipment's user manual.

Selection Guide and Purchasing Advice

When selecting a CANopen cordset, consider cable length, connector type, and environmental protection. For longer runs, consider other lengths in the same series. AutoDCSTech stocks this cordset and can advise on alternatives for extended distances. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
