Technical Specifications Breakdown
Key parameters for the TSXCANCD50 are listed below for quick reference:
| Feature | Specification |
|---|---|
| Product Type | CANopen cable |
| Bus Type | CANopen |
| Cable Length | 164.04 ft (50 m) |
| IP Degree of Protection | IP20 |
| Marking | CE |
| Product Weight | 7.74 lb(US) (3.51 kg) |
Industry Applications
This cable is commonly used in packaging lines, material handling systems, and automotive assembly stations where CANopen networks link drives, sensors, and controllers. The 50-meter length allows flexible routing between cabinets and field devices, reducing the need for intermediate junction boxes. In a typical automotive plant, the TSXCANCD50 connects a remote I/O station to a main controller, maintaining signal integrity despite exposure to vibration and temperature fluctuations.
Installation & Setup Guidance
When installing the TSXCANCD50, ensure the cable is routed away from high-voltage power cables to avoid electromagnetic interference. Use proper strain relief at both ends to prevent mechanical stress on the connectors. The IP20 rating means the cable is suitable for use inside enclosures or in dry, indoor locations. Verify that the CANopen network terminator resistors are correctly placed at both ends of the bus for reliable communication.
Maintenance & Reliability
Periodically inspect the cable for cuts, kinks, or abrasion, especially near connection points. Keep the cable clean and free of dust accumulation. The CE marking indicates compliance with European health, safety, and environmental protection standards, supporting reliable operation in industrial settings. No special maintenance tools are required beyond routine visual checks.
Reliable CANopen Connectivity for Demanding Industrial Environments
In modern manufacturing, a single communication failure can halt an entire production line, causing costly downtime. The Schneider TSXCANCD50 CANopen cable is engineered to withstand harsh industrial conditions, ensuring robust data transmission over long distances.
Compatibility & Integration
The TSXCANCD50 is designed for CANopen bus systems within the Schneider CANopen range. It works with Schneider drives, I/O modules, and controllers that support CANopen protocol. The cable uses standard CANopen connectors, making it compatible with many third-party devices that adhere to the CANopen standard.
Selection Guide & Purchasing Advice
When selecting a CANopen cable, consider the distance between devices and environmental conditions. The TSXCANCD50 offers a proven solution for 50-meter runs in harsh environments. AutoDCSTech stocks this cable for immediate shipment, ensuring you can maintain or expand your network without delay. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
Availability & Condition at AutoDCSTech
| Part Number | TSXCANCD50 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | France |
