Schneider TSXDSY08R5A Discrete Output Module for TSX Micro PLCs

Technical Specifications Breakdown

Key parameters for the TSXDSY08R5A are listed below for quick reference:

Industry Applications

Manufacturing Line Control

In automated assembly lines, the module's eight relay-protected outputs can drive solenoids, contactors, and indicator lights. The wide voltage range (24...240 V AC) allows direct connection to standard industrial actuators without external converters. The fast response times (< 10 ms activation) ensure precise timing in high-speed processes.

HVAC System Management

For building automation, the TSXDSY08R5A can control fans, pumps, and dampers. The RC circuit and Ge-Mov overvoltage protection safeguard against voltage spikes from inductive loads, extending equipment life.

Material Handling Systems

In conveyor and sorting systems, the module's electrical durability (1,000,000 cycles for resistive loads) ensures reliable operation over years of service. The screw terminal block simplifies field wiring, reducing installation time and costs.

Installation & Setup Guidance

Mount the module securely in a standard TSX Micro PLC rack. Use the screw terminal block for wire connections, ensuring tight torque to prevent loosening. Verify the power supply voltage matches the rack requirements (24 V DC for rack consumption). For output wiring, connect loads within the specified voltage range (24...48 V DC or 24...240 V AC) and do not exceed the conventional free air thermal current of 5 A per output. The module is IP20 rated, so install it in a clean, dry enclosure to maintain protection.

Maintenance & Reliability

Periodically inspect the module for signs of dust or moisture accumulation. The ambient temperature for operation is 0...60 °C, and storage range is -25...70 °C. Keep relative humidity between 10...95% (non-condensing) during operation. Check the 6.3 A fuse per common for continuity if outputs fail; replace only with the same rating. The module's electrical durability of 1,000,000 cycles for resistive loads underlines its long service life.

Compatibility & Integration

The TSXDSY08R5A is designed for the Modicon Premium Automation platform and TSX Micro PLCs. It integrates with Schneider's IEC 61131-2 compliant systems. The module carries CE marking and certifications including UL 508, CSA C22.2 No 142, and various marine approvals (DNV, LR, ABS, BV, RMRS, GL, RINA). Ensure your PLC firmware supports this module version.

Selection Guide & Purchasing Advice

When ordering the TSXDSY08R5A, verify its lifecycle status with AutoDCSTech to ensure availability. For larger systems, consider additional modules. AutoDCSTech offers competitive pricing and fast shipping for this and other Schneider components.

Troubleshooting & Common Issues
