SED4D-06: Digital Terminal Board
The SED4D-06 is the Digital Terminal Board covered on this page. The attribute that decides whether it fits the existing installation without modification is 16 channels x 2.
This configuration's digital terminal board is the attribute that drives the replacement decision. A terminal board or cable is the physical interface between the control system and the field wiring, and its configuration is about connector type, signal routing and termination rather than processing. digital terminal board sets how the signals are landed and distributed, and whether the board mates with the existing harness. Confirming 16 channels x 2 against the original assembly avoids a board that bolts in but does not connect.
| Feature | Specification |
|---|---|
| Manufacturer | Yokogawa |
| Brand | Yokogawa |
| Part Number | SED4D-06 |
| Product Type | Digital Terminal Board |
| Channels | 16 channels x 2 |
| Suffix Code 1 | 0 = Without surge absorber |
| Suffix Code 2 | 6 = With ISA Standard G3 |
| Terminal | M4 screw |
| Weight | 1.5 kg |
| Connection Cable | AKB331 |
| Withstand Voltage | 500 V AC (1 min) |
| Insulation Resistance | 100 MΩ min (500 V DC) |
· Last updated:
Availability & Condition at AutoDCSTech
| Part Number | SED4D-06 |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | Japan |
