TCSESM083F2CS0 | Schneider Electric 6-Port Managed Switch

Introduction: The Evolution Toward Deterministic Industrial Networks

Industrial automation has evolved from isolated relay logic to interconnected control architectures. As factories embraced Ethernet TCP/IP, engineers needed switches that could survive the plant floor while delivering deterministic performance. The Schneider Electric ConneXium TCSESM083F2CS0 answers that need. This managed switch combines six copper ports with two single-mode fiber uplinks, enabling long-distance backbone connections across large facilities. Consequently, it supports the Transparent Ready concept, which unifies control and information systems over one network infrastructure.

TCSESM083F2CS0 Technical Specifications

• Product type: Ethernet TCP/IP managed switch
• Ports: 6 x RJ45 10/100BASE-TX copper + 2 x 100BASE-FX single-mode fiber (SC)
• Supply voltage: 24V DC
• Switching capacity: 5.6 Gbps
• MAC table size: 8K entries
• Jumbo frame: 9216 bytes
• Redundancy: HiPER ring, RSTP
• Max ring nodes: 50
• Protection rating: IP20
• Mounting: 35 mm symmetrical DIN rail

Each specification reflects engineering-grade precision. The 5.6 Gbps switching capacity handles full wire-speed traffic across all ports simultaneously. Meanwhile, the 8K MAC table supports dense device populations without flooding. The 9216-byte jumbo frame capability reduces fragmentation for large data transfers. Additionally, the HiPER ring protocol supports up to 50 nodes, providing fast recovery for ring topologies. The IP20 rating suits control cabinets, and the 35 mm DIN rail mount simplifies panel installation.

Managed Functionality and Protocol Support

As a managed switch, the TCSESM083F2CS0 offers configuration and monitoring beyond simple connectivity. It supports Ethernet TCP/IP, SSH, HTTP, HTTPS, SNMP, RS232, LLDP, Telnet, SNTP, and MRP. Therefore, network engineers can implement secure remote management via SSH and HTTPS. SNMP enables integration with network management systems, while LLDP simplifies topology discovery. The SNTP protocol synchronizes device clocks across the network. Furthermore, port hardening provides cybersecurity at the access layer, restricting unauthorized device connections.

Deployment Scenarios for the TCSESM083F2CS0

This switch fits applications requiring reliable backbone connectivity. In automotive assembly lines, the single-mode fiber ports link distant control cabinets across the plant. Similarly, water treatment facilities use fiber uplinks to connect remote pump stations to a central SCADA system. Because the switch supports HiPER ring, it also suits conveyor systems where cable redundancy prevents production stops. The 24V DC supply aligns with standard industrial power distribution. Consequently, integrators can deploy the TCSESM083F2CS0 in control panels without additional power conditioning.

Integration and Installation Notes

Mount the TCSESM083F2CS0 on a 35 mm symmetrical DIN rail inside an IP20-rated enclosure. Verify that the 24V DC supply meets the switch's input requirements before energizing. For fiber connections, use SC-type single-mode connectors matched to the 100BASE-FX interface. When integrating into managed networks, confirm that your network management platform supports SNMP or SSH for configuration. If your architecture uses a fieldbus protocol not listed in the specifications, consult Schneider Electric documentation for gateway options. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
