Evaluating the IC200CHS022 for Your Automation Needs
When selecting an I/O carrier for your VersaMax system, the IC200CHS022 offers a compact box-style design with 36 terminals. This module provides field wiring, mounting, and backplane communications for one VersaMax I/O module. Understanding its specifications and application fit is essential for a successful purchase.
Key Specifications at a Glance
The IC200CHS022 is a compact box-style I/O carrier from the VersaMax series, manufactured by Emerson Automation (formerly GE Fanuc). It features 36 screw-type terminals labeled A1-A18 and B1-B18, arranged on three terminal strips. Each point is rated for up to 2 Amps of current, while each power and ground segment supports up to 8 Amps. The voltage rating is 0-264 VAC, with a transient voltage rating up to 300 VAC.
For wiring, the carrier accepts single copper wire from AWG #14 to AWG #22 (cross section 0.36 mm² to 2.1 mm²) or two wires up to AWG #18 (0.86 mm²). The module dimensions are 66.8 x 70 x 163.5 mm, and it mounts on a DIN rail or panel. Proper clearance of 2 inches top/bottom and 1 inch sides is recommended.
Application Scenarios for the IC200CHS022
This carrier is ideal for discrete manufacturing and process control applications where modular I/O is needed. In a typical packaging line, the IC200CHS022 can host input modules for sensors and output modules for actuators, simplifying wiring and troubleshooting. Its 36 terminals provide ample connection points for field devices, and the ability to replace I/O modules without removing wiring reduces downtime.
Another common use is in material handling systems, where the carrier's compact size fits into tight control panels. The IC200CHS022 is suitable for Class I, Division 2, Groups A, B, C, and D, and Class 1 Zone 2 hazardous locations, making it a versatile choice for many industrial environments.
Compatibility and Integration
The IC200CHS022 is compatible with all VersaMax I/O modules, which mount vertically on the carrier. It provides backplane communications between the module and the system. The carrier includes a card holder that locks the I/O module in place and must be in the retracted position during operation. A wiring card can be inserted into the holder for labeling.
For mounting, the carrier supports DIN rail (7.5 x 35 mm) or panel mounting. Ensure adequate clearance for airflow and maintenance. The module's enclosure depth is 70 mm, so plan your cabinet layout accordingly.
Frequently Asked Questions
What is the maximum voltage per point on the IC200CHS022?
The maximum voltage per point is 264 VAC. The carrier can also withstand transient voltages up to 300 VAC.
How many wires can be connected to a single terminal?
Each terminal can accommodate one or two copper wires. For a single wire, use AWG #14 to AWG #22. For two wires, use AWG #18.
Is the IC200CHS022 suitable for hazardous locations?
Yes, it is rated for Class I, Division 2, Groups A, B, C, and D, and Class 1 Zone 2 locations. Always verify local codes and installation requirements.
Can I replace the I/O module without removing wiring?
Yes, the carrier allows the hosted VersaMax I/O module to be replaced or serviced without disturbing existing wiring connections. This reduces troubleshooting and downtime.
