330930-045-01-CN 4.5m Bently Nevada Extension Cable

Introduction: The Evolution of Vibration Monitoring

Industrial machinery has grown more complex, and so has the need for precise vibration monitoring. The 330930-045-01-CN from Bently Nevada represents a key link in the 3300 NSv system, ensuring that signals from the probe reach the monitor without degradation. This extension cable is engineered for harsh environments, where reliability is non-negotiable.

Key Features & Technical Specifications

The 330930-045-01-CN is a 3300 NSv extension cable with a length of 4.5 meters (14.8 feet). It features a 75 Ω coaxial construction with fluoroethylene propylene (FEP) insulation, ensuring stable impedance and signal integrity. The cable is armored with stainless steel and has an FEP jacket, providing excellent mechanical protection. Its gold-plated brass connectors offer corrosion resistance and reliable contact. The operating temperature range is -51°C to +177°C (-60°F to +351°F), making it suitable for extreme conditions. The shipping weight is 1.5 kg.

• Cable Length: 4.5 meters (14.8 feet)
• Impedance: 75 Ω coaxial
• Insulation: FEP (fluoroethylene propylene)
• Armor: Stainless steel with FEP jacket
• Connector Material: Gold-plated brass
• Temperature Range: -51°C to +177°C (-60°F to +351°F)
• Shipping Weight: 1.5 kg

Applications & Use Cases

This extension cable is used in rotating machinery monitoring systems, including turbines, compressors, and pumps. It connects the proximity probe to the Proximitor Sensor, ensuring accurate vibration and position measurements. In petrochemical plants, where temperatures fluctuate, the FEP insulation and stainless steel armor provide long-term reliability. Similarly, in power generation facilities, the cable's robust construction withstands continuous operation. Its country-specific approval (CN) ensures compliance with local regulations.

Installation & Setup

Proper installation is critical for accurate readings. First, verify that the total length of the probe and extension cable matches the Proximitor Sensor's specified length. The extension cable's DC resistance is 0.220 Ω/m for the center conductor and 0.066 Ω/m for the shield. Field wiring should use a three-conductor shielded triad cable, with a maximum length of 305 meters (1,000 feet) between the Proximitor Sensor and the monitor. Ensure that all connections are tightened securely, and avoid sharp bends that could damage the cable.

Maintenance & Reliability

Routine inspection of the cable and connectors is essential to prevent signal loss. Check for any signs of wear, corrosion, or damage to the armor. Because the cable operates in extreme temperatures, verify that the FEP jacket remains intact. Periodically test the cable's capacitance, which is typically 69.9 pF/m (21.3 pF/ft), to ensure it remains within specification. Following the manufacturer's guidelines for maintenance will extend the service life of the cable and maintain measurement accuracy.

Compatibility & Integration

The 330930-045-01-CN is designed for the Bently Nevada 3300 NSv system. It works with 3300 NSv Proximitor Sensors and compatible monitors. The extension cable is available with optional stainless steel armor, and the connector option includes FEP jacket. The linear range of the system is 1.5 mm (60 mils), with a recommended gap setting of 1.0 mm (40 mils). This cable ensures that the signal from the probe is transmitted without significant loss, even over long distances.

Troubleshooting & Common Issues

Signal degradation can occur if the cable length is not matched correctly. Always confirm that the sum of the probe length and extension cable length equals the Proximitor Sensor's total length. Additionally, high capacitance in the cable can cause signal rolloff at high frequencies. If you experience erratic readings, check the field wiring connections and ensure that the shield is properly grounded. The tensile strength of the cable is rated at 220 N (50 lb) at the connectors, so avoid exceeding this limit during installation.

Product Support & Availability

The 330930-045-01-CN is available from AutoDCSTech. Contact us for current availability and lifecycle status. We are an industrial automation parts supplier dedicated to providing quality components.
