Allen-Bradley 150-F780NCA SMC Flex Solid State Controller 780A

Product Overview

The Allen-Bradley 150-F780NCA is an SMC Flex Smart Motor Controller designed for high-power motor control. This solid state controller delivers up to 780 A continuous current and supports motors rated 600 Hp at 460V AC. It is built for demanding industrial environments requiring reliable starting and stopping of large AC motors.

Technical Specifications Breakdown

Key parameters for the 150-F780NCA are listed below for quick reference:

Industry Applications

The 780 A rating and 600 Hp capacity make it suitable for high-inertia loads where smooth acceleration is critical. By using an SMC Flex controller, operators reduce mechanical stress and improve process control.

Installation & Setup Guidance

Mount the open enclosure in a clean, dry electrical cabinet with adequate ventilation. Ensure the input line voltage matches the 200-575V AC 3-phase supply. The control voltage must be 230/240V AC for proper operation. Connect incoming line terminations at the top and motor connections at the bottom. Use conductors sized for 780 A continuous current.

Maintenance & Reliability

Inspect the heatsink fan and enclosure for dust buildup periodically. Verify all power and control connections are tight. Monitor the LCD display for fault codes. The IP00 rated open enclosure requires protection from contaminants in the installation environment.

Selection Guide & Purchasing Advice

When selecting a solid state controller, verify that the motor full-load current does not exceed 780 A and that the supply voltage is within 200-575V AC. The 150-F780NCA is available from AutoDCSTech. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
