Allen-Bradley 1792D-16BVT0CD ArmorBlock MaXum I/O Module Overview

Product Overview

Maintenance engineers often face challenges with distributed I/O in harsh environments. The Allen-Bradley 1792D-16BVT0CD I/O module from the ArmorBlock MaXum series addresses this need with a rugged, sealed housing that eliminates the need for a protective enclosure. This 16-input module communicates via DeviceNet, providing full diagnostic capabilities accessible through Y splitter cables. It supports DeviceLogix for local control, making it a versatile choice for decentralized automation.

Technical Specifications Breakdown

Key parameters for the 1792D-16BVT0CD are listed below for quick reference:

Industry Applications

With 16 inputs accepting both PNP and NPN devices, it suits diverse sensor types. The sealed housing withstands washdown environments, reducing downtime from moisture ingress. The DeviceNet interface simplifies wiring and diagnostics, lowering total cost of ownership.

Installation and Setup Guidance

Mount the module in a location within the operating temperature range of -25 to 60 degrees Celsius. Use wiring of 14 to 22 AWG with insulation. Configure the communication rate between 125 and 500 kilobytes per second to match your network. The module supports both PNP and NPN devices; set inputs accordingly. No protective enclosure is needed due to the sealed design.

Maintenance and Reliability

Periodically inspect the module for physical damage or contamination. The sealed housing reduces maintenance needs, but verify that connectors and cables remain secure. The module provides diagnostic information for issues like short circuits or open wires, enabling proactive repairs. Store the module within -25 to 80 degrees Celsius when not in use.

Compatibility and Integration

It works with Allen-Bradley controllers and other DeviceNet-compatible devices. The module supports DeviceLogix for local logic execution, reducing reliance on a central controller. Use Y splitter cables to access diagnostic data.

Selection Guide and Purchasing Advice

When selecting this module, consider your input count and device type. The 1792D-16BVT0CD offers 16 inputs and accepts PNP or NPN devices. For reliable supply, purchase from AutoDCSTech, a trusted source for industrial automation parts. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
