Technical Specifications Breakdown
Key parameters for the 20F11ND096JA0NNNNN are listed below for quick reference:
| Feature | Specification |
|---|---|
| Manufacturer | Allen Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 753 |
| Voltage Rating | 480 Volts AC and 650 Volts DC |
| Current Rating | 96 Amperes |
| Output Power Rating | 55.9 kilowatts |
| Horsepower Rating | 75 horsepower |
| Rated Phase | 3-phase |
| Frequency Tolerance | 47 to 63 Hertz |
| Ambient Operating Temperature | 0 to 40°C (in a non-condensing environment) |
| Storage Temperature | -40 to 70°C (in a non-condensing environment) |
| Weight | 85.00 lbs (38.56 kg) |
| Cooling Method | Air cooling |
| Filtering | Filter included |
| Braking Unit | Internal transistor included |
| User Interface | No Human Interface Module (HIM) |
| Input Type | AC input with precharge and DC terminals |
Industry Applications and Benefits
This AC drive is well-suited for a wide range of industrial applications, including conveyors, pumps, fans, compressors, and material handling systems. The 96-amp output and 75-horsepower rating enable it to handle medium-to-large motor loads efficiently. The built-in filter reduces electrical noise, enhancing system reliability in sensitive environments. The internal braking transistor provides dynamic braking capability, allowing rapid deceleration and improved process control.
Installation and Setup Guidance
When installing this drive, ensure the ambient temperature remains between 0 and 40°C in a non-condensing environment. Mount the unit in a clean, dry location with adequate airflow for air cooling. The AC input with precharge and DC terminals offers flexible wiring options. Note that this model does not include a Human Interface Module (HIM); you will need an external HIM or a communication adapter for programming and monitoring. Always follow the manufacturer's manual for proper wiring and configuration.
Maintenance and Reliability
Routine inspection of the cooling fan and air filters is recommended to maintain thermal performance. Verify that the storage temperature range (-40 to 70°C) is respected when the drive is not in service. Periodically check all power connections for tightness and signs of wear. The included common mode capacitor connection jumper simplifies setup for common mode filtering.
Robust AC Drive for Industrial Motor Control
The Allen-Bradley PowerFlex 753 series delivers versatile AC drive solutions for demanding industrial environments. The 20F11ND096JA0NNNNN is engineered to provide reliable variable speed control for three-phase motors, combining compact design with embedded I/O and standard protection features. This drive is an choice for applications requiring precise speed regulation, energy savings, and reduced mechanical stress on equipment.
Selection Guide and Purchasing Advice
For engineers seeking a reliable AC drive with robust performance, the 20F11ND096JA0NNNNN offers a proven solution. AutoDCSTech stocks this model and can assist with availability and lifecycle status. Please verify current lifecycle status and availability with AutoDCSTech before ordering. Their team can also help identify compatible accessories, such as HIM modules or communication options, to tailor the drive to your specific application.
Availability & Condition at AutoDCSTech
| Part Number | 20F11ND096JA0NNNNN |
|---|---|
| Availability | In Stock |
| Condition | New |
| Warranty | One Year |
| Origin | US |
