Allen-Bradley 22F-D018N104 PowerFlex 4M VFD, 7.5 kW, 18 A

Technical Specifications Breakdown

Key parameters for the 22F-D018N104 are listed below for quick reference:

Industry Applications

• Conveyor Systems: The 22F-D018N104 provides smooth acceleration and deceleration, reducing mechanical stress on conveyor belts and gearboxes.
• Pumps and Fans: Variable speed control allows you to match motor speed to process demand, saving energy and reducing wear.
• Packaging Machinery: Precise speed regulation ensures consistent product flow and accurate cut-to-length operations.

Installation and Setup Guidance

Panel mounting is the primary installation method for this drive. For environments with high shock or vibration, panel mounting is recommended over DIN rail to enhance stability. The drive features feed-through wiring, simplifying wiring in tight panels. Use the embedded keypad with a 4-digit display to quickly configure the 12 most common application parameters. The RS485 port enables multi-drop network connections for centralized control.

Maintenance and Reliability

Periodically inspect the drive for dust buildup on the cooling fins and ensure airflow is not obstructed. Operating temperature can be up to 50 degrees Celsius with minimal spacing between drives; zero stacking is possible up to 40 degrees Celsius. Check all wiring connections for tightness during routine maintenance.

PowerFlex 4M VFD for Reliable Motor Control

This PowerFlex 4M drive provides dependable speed control for three-phase AC motors up to 7.5 kW (10 HP). Its space-saving design and straightforward programming make it a practical choice for original equipment manufacturers and panel builders.

Compatibility and Integration

The built-in RS485 port supports DSI protocol, allowing integration with various control systems. Optional communication modules are available for BacNet, LonWorks, ProfiBus, Ethernet, DeviceNet, and ControlNet, providing flexibility for different network architectures. The discrete I/O includes five sink/source inputs, one Form C relay output, and one analog input (0-10VDC or 0-20mA), enabling remote start/stop, speed reference, and status feedback.

Purchasing Advice

When selecting a VFD, verify that the input voltage and current ratings match your facility's power supply. The 22F-D018N104 is designed for 480VAC three-phase systems. For branch circuit protection, use the recommended Allen-Bradley fuse (140M-C2E-B40) and contactor (100-C09). Contact AutoDCSTech to confirm availability and lead times before ordering. Our team can help you find the right drive for your application.
