What Is the Bently Nevada 200151-20-02-00?
When a vibration monitoring system fails due to cable degradation, the Bently Nevada 200151-20-02-00 provides a robust solution. This accelerometer interface standard cable, part of the 200151 series, connects transducers to monitoring hardware with connectors on both ends. Designed for harsh industrial environments, it ensures signal integrity for accurate data collection.
Technical Specifications Breakdown
The 200151-20-02-00 cable features a 2.0-meter length, ideal for tight installations. It uses a blue cable without armor, as indicated by the -02 option. The construction includes 4 conductors, 22 AWG, with a braided shield and drain wire (85% coverage, minimum), and a PVC outer jacket. Nickel-plated coupling nuts provide corrosion resistance. Connectors achieve an IP67 seal to transducers and mating hardware, with DC4 electrical insulating compound added for moisture protection during thermal shock. The minimum bend radius is 63.5 mm (2.5 in), ensuring flexibility without damage. Operating temperature range is -20 ºC to +100 ºC (-4 ºF to +212 ºF), though lower temperatures are acceptable if the cable is not flexed.
Industry Applications
In rotating machinery monitoring, the 200151-20-02-00 transmits vibration signals from accelerometers to Bently Nevada systems, enabling early fault detection. In oil and gas facilities, its IP67 seal and robust construction resist moisture and thermal shock, ensuring reliable operation in demanding conditions. The cable's 4-conductor design supports both signal and power for active sensors.
Installation & Setup Guidance
When installing the 200151-20-02-00, ensure the cable is routed with a bend radius no smaller than 63.5 mm to avoid internal damage. Connect the nickel-plated coupling nuts firmly to transducers and mating hardware to achieve the IP67 seal. Avoid flexing the cable at temperatures below -20 ºC (-4 ºF) to prevent damage. Use the drain wire for proper grounding to maintain shield effectiveness.
Maintenance & Reliability
Inspect the cable periodically for cuts, abrasions, or connector damage. Verify the coupling nuts remain tight to preserve the IP67 seal. The PVC outer jacket resists many industrial chemicals, but avoid prolonged exposure to solvents. For long-term reliability, replace cables showing signs of wear before they compromise signal quality.
Compatibility & Integration
The 200151-20-02-00 is designed for Bently Nevada accelerometer systems that use standard interface cables with connectors on both ends. It works with compatible transducers and monitoring hardware from the 200151 series. Verify connector types match your equipment before ordering.
Selection Guide & Purchasing Advice
Before purchasing the 200151-20-02-00, confirm your required cable length (2.0 meters) and armor option (blue without armor). Ensure your system uses connectors on both ends. For current lifecycle status and availability, contact SpareTechPLC, your reliable supplier for industrial automation parts.
Frequently Asked Questions
What is the cable length of the 200151-20-02-00?
The cable length is 2.0 meters, as indicated by the -20 in the part number.
What is the operating temperature range?
The operating temperature range is -20 ºC to +100 ºC (-4 ºF to +212 ºF). Flexing below -20 ºC may damage the cable.
Does the cable have connectors on both ends?
Yes, the 200151-20-02-00 has connectors on both ends, as specified by the product type.
What is the shield coverage?
The cable has a braided shield with minimum 85% coverage and a drain wire.
Is the cable suitable for outdoor use?
The cable provides an IP67 seal to transducers and mating hardware, making it suitable for wet or dusty environments, but the PVC jacket is not UV-rated for prolonged sun exposure.
