Bently Nevada 330101-00-45-15-02-00 3300 XL 8 mm Probe

Technical Specifications Breakdown

Key parameters for the 330101-00-45-15-02-00 are listed below for quick reference:

Industrial Applications for Reliable Monitoring

The robust PPS tip and stainless steel case withstand oil, moisture, and temperature extremes common in power generation and oil & gas facilities.

Installation and Setup Guidance

Proper installation is critical for accurate readings. The 3/8-24 UNF thread requires careful engagement: maximum thread engagement is 0.563 in. For standard forward-mounted probes, use the recommended torque of 11.2 N•m (100 in•lbf) on the case, and 7.5 N•m (66 in•lbf) on the first three threads. Ensure the probe tip is clean and the target surface is smooth. The recommended gap setting for radial vibration is -9 Vdc (approximately 1.27 mm or 50 mils). Field wiring should use 3-conductor shielded triad cable, 0.2 to 1.5 mm² (16 to 24 AWG), with a maximum length of 305 meters (1,000 feet) to the Proximitor sensor.

Maintenance and Reliability Tips

Inspect the probe cable and connector periodically for wear or damage. The patented CableLoc design provides 330 N (75 lbf) pull strength, but avoid excessive bending at the connector. For applications with high humidity, the optional FluidLoc cable prevents liquid ingress. The probe is designed to seal differential pressure with a Viton O-ring; contact AutoDCSTech if pressure testing is required. Store the probe within its temperature range (-52°C to +177°C) to maintain accuracy.

Robust Vibration Sensing for Critical Machinery

As a maintenance engineer, you know that reliable vibration data is the cornerstone of predictive maintenance. The Bently Nevada 330101-00-45-15-02-00 3300 XL 8 mm probe delivers the precision and durability needed to protect your rotating assets. This non-contact eddy current probe is engineered for continuous monitoring in harsh environments, providing accurate shaft relative vibration measurements.

Selection Guide and Purchasing Advice

When selecting a replacement or new probe, verify the thread type (3/8-24 UNF) and total length (1.5 m). The 330101-00-45-15-02-00 includes a miniature coaxial ClickLoc connector for secure, quick installation. For extended temperature ranges up to +218°C, consider the ETR probe variant. AutoDCSTech stocks this Bently Nevada probe and can advise on compatibility with your existing 3300 XL system. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
