Bently Nevada 330101-30-63-10-02-00 3300 XL 8 mm Probe

Precision Vibration Monitoring with the Bently Nevada 330101-30-63-10-02-00

Industrial rotating machinery demands reliable, accurate vibration measurement to prevent catastrophic failures. The Bently Nevada 330101-30-63-10-02-00 3300 XL 8 mm probe delivers the ruggedness and precision required for continuous protection in harsh environments.

Technical Specifications Breakdown

Key parameters for the 330101-30-63-10-02-00 are listed below for quick reference:

Industry Applications and Failure Prevention

Its 2 mm linear range and high sensitivity (7.87 V/mm) provide early detection of shaft misalignment, imbalance, or bearing wear. By catching these issues early, maintenance teams can avoid unplanned downtime and extend equipment life.

Installation and Setup Guidance

Mount the probe using the 3/8-24 UNF thread with a recommended torque of 11.2 N•m (100 in•lbf) for standard forward mounting. For the first three threads, use 7.5 N•m (66 in•lbf). Set the recommended gap to -9 Vdc (approximately 1.27 mm or 50 mils) for radial vibration measurement. Ensure field wiring uses 0.2 to 1.5 mm² (16 to 24 AWG) three-conductor shielded triad cable, with a maximum length of 305 meters (1,000 feet) to the monitor.

Maintenance and Reliability

The probe’s patented TipLoc and CableLoc designs provide a robust bond and 330 N (75 lbf) pull strength. Standard probes operate from -52°C to +177°C. Avoid exposing the probe to temperatures below -34°C (-30°F) to prevent premature pressure seal failure. The Viton® O-ring seals differential pressure between tip and case.

Compatibility and Integration

This probe works with Bently Nevada 3300 XL extension cables and Proximitor sensors. The miniature coaxial ClickLoc connector ensures secure, quick connections. The system provides a deviation from best fit straight line (DSL) of less than ±0.025 mm (±1 mil) over the 80 mil linear range at 0°C to +45°C.

Selection Guide and Purchasing Advice

When ordering, verify the total length option (1.0 meter) and agency approval (not required). For applications requiring higher temperature tolerance, consider the extended temperature range probe (tip up to +218°C). AutoDCSTech offers this exact model with fast shipping and expert support. Please verify current lifecycle status and availability with AutoDCSTech before ordering.
