Bently Nevada 330101-36-80-10-02-00 3300 XL 8 mm Probe

Technical Specifications Breakdown

Key parameters for the 330101-36-80-10-02-00 are listed below for quick reference:

Industrial Applications and Operational ROI

By providing early warning of developing faults, it helps avoid unscheduled maintenance and extends equipment life. The robust PPS tip and stainless steel case withstand harsh industrial environments, reducing replacement frequency and total cost of ownership.

Installation and Setup Guidance

Proper installation is critical for accurate readings. The 3/8-24 UNF thread allows secure mounting into standard bore holes. Use the recommended torque values: 11.2 N•m (100 in•lbf) for standard forward mounted probes. Ensure thread engagement does not exceed 0.563 inches. The miniature coaxial ClickLoc connector simplifies cable attachment and reduces signal loss.

Maintenance and Reliability

The probe is designed for long-term reliability. The patented TipLoc molding method provides a robust bond between tip and body, while the CableLoc design delivers 330 N (75 lbf) pull strength. Inspect the probe and cable periodically for physical damage. The probe operates reliably in high humidity environments, with less than 3% change in Average Scale Factor after 56 days at 93% humidity per IEC 68-2-3.

Reliable Vibration Sensing for Critical Machinery

In rotating machinery, undetected shaft vibration can lead to catastrophic failure and unplanned downtime. The Bently Nevada 330101-36-80-10-02-00 3300 XL 8 mm Probe provides the precision measurement needed to protect your assets. Designed for permanent installation, this eddy-current probe delivers accurate displacement data to your monitoring system.

Compatibility and Integration

This 3300 XL probe is compatible with Bently Nevada 3300 XL Proximitor sensors and extension cables. The standard 1.0 meter system provides a nominal probe DC resistance of 7.59 ± 0.50 Ω. Field wiring up to 305 meters (1000 feet) is supported using 3-conductor shielded triad cable. Please verify current lifecycle status and availability with AutoDCSTech before ordering.

Selection Guide and Purchasing Advice

When selecting a replacement or new probe, verify the thread size (3/8-24 UNF), cable length, and connector type. Contact AutoDCSTech for expert assistance in matching this probe to your monitoring system.
