Product Overview
When your production line demands precise and reliable motor control, the FANUC A06B-6140-H055 servo amplifier module delivers the performance you need. As part of the trusted A06B series, this unit is engineered to handle high-power applications with ease. With a voltage class of 200V and a rated input voltage range of 200 to 240 VAC, it fits seamlessly into standard industrial power systems. The main input current of 228 A ensures robust operation, making it a solid choice for demanding environments.
Technical Specifications Breakdown
Understanding the key parameters of the A06B-6140-H055 helps you plan your system integration. This module operates on a 3-phase voltage setup with an input frequency of 50/60 Hz, providing flexibility across different regional power standards. Its rated output voltage range of 283 to 339V and rated output current of 65 kW enable it to drive large servo motors efficiently. The dimensions—38 cm in height, 30 cm in width, and 27.2 cm in length—allow for straightforward mounting in standard cabinets. At 45.00 lbs (20.41 kg), it offers a robust build without sacrificing ease of handling during installation.
Industry Applications
From CNC machining centers to robotic workcells, the A06B-6140-H055 excels in applications requiring high torque and precise speed control. In a typical automotive assembly line, this servo amplifier module powers the axes of a multi-axis robot, ensuring smooth and repeatable movements. Its 65 kW output capacity also suits large conveyor systems in material handling, where consistent acceleration and deceleration reduce wear on mechanical components. For maintenance engineers, the module’s straightforward design simplifies troubleshooting, keeping downtime to a minimum.
Installation and Setup Guidance
Mount the A06B-6140-H055 securely in a clean, dry enclosure with adequate airflow. Ensure the 3-phase input voltage matches your facility’s supply within the 200 to 240 VAC range. Use appropriately rated conductors for the 228 A main input current. Connect the output to your servo motor, verifying polarity and phase sequence. After power-up, check the rated output voltage (283 to 339V) at the motor terminals to confirm proper operation. Always follow FANUC’s installation manual for detailed wiring diagrams and safety precautions.
Maintenance and Reliability
Regular inspection of the A06B-6140-H055 extends its service life and prevents unexpected failures. Check for dust accumulation on heat sinks and fans, as this can reduce cooling efficiency. Verify that all power connections remain tight and free of corrosion. Monitor input voltage and current levels periodically to ensure they stay within the rated 200 to 240 VAC and 228 A limits. By following these simple steps, you maintain the reliability that FANUC is known for, reducing total cost of ownership.
Compatibility and Integration
The A06B-6140-H055 integrates with FANUC CNC and servo systems, providing seamless communication and control. It is designed to work with FANUC servo motors that match its output specifications. For best performance, pair it with compatible FANUC power supplies and controllers. This module is a direct replacement for earlier A06B series amplifiers, simplifying upgrades in existing machinery. Always verify model numbers and revision levels with your system documentation.
Selection Guide and Purchasing Advice
Before ordering the A06B-6140-H055, confirm that your application requires a 3-phase, 200-240 VAC input and 65 kW output capacity. Check the physical dimensions (38 x 30 x 27.2 cm) to ensure fit in your cabinet. SpareTechPLC stocks this servo amplifier module and can help you verify compatibility with your current system. Contact our team for current availability and lifecycle status to ensure timely delivery for your project.
Frequently Asked Questions
Q: What is the input voltage range for the A06B-6140-H055?
A: The rated input voltage is 200 to 240 VAC, 3-phase, at 50/60 Hz.
Q: What is the output power rating of this servo amplifier?
A: The rated output current is 65 kW, with an output voltage range of 283 to 339V.
Q: What are the dimensions and weight of the A06B-6140-H055?
A: It measures 38 cm high, 30 cm wide, and 27.2 cm deep, weighing 45.00 lbs (20.41 kg).
Q: Can this module be used with non-FANUC motors?
A: It is optimized for FANUC servo motors; consult your system integrator for alternative compatibility.
Q: How do I verify the lifecycle status of this product?
A: Please contact SpareTechPLC for current lifecycle information and replacement options.
