Product Introduction
When a PLC rack backplane loses stable power, system downtime and data loss become immediate risks. The GE Fanuc IC200PWR101 power supply module from the Versamax series delivers consistent power to network interface units, I/O units, and central processing units. Designed for both main and supplemental power roles, this module supports flexible system configurations. Its input voltage of 120/240 Volts AC and output voltages of 5 Volts DC and 3.3 Volts DC make it a reliable choice for industrial automation environments.
Technical Specifications Breakdown
Key specifications from the IC200PWR101 include:
- Input Voltage: 120/240 Volts AC – supports standard industrial AC mains.
- Output Voltage: 5 Volts DC and 3.3 Volts DC – provides dual-rail power for logic and I/O circuits.
- Input Power: 27 volt-amperes – low power draw for efficient operation.
- Holdup Time: 20 milliseconds – maintains output during brief power interruptions.
- Protection: Short circuit, overload – safeguards connected modules.
- Total Output Current: 1.5 Amperes maximum – sufficient for typical rack loads.
- 3.3V Output Current: 0.25 Amperes maximum – dedicated rail for low-voltage devices.
- 5V Output Current: 1.5 Amperes minus the 3.3 Volts current used, maximum – shared capacity for 5 V loads.
These parameters ensure stable backplane power delivery under normal operating conditions.
Industry Applications
In discrete manufacturing, the IC200PWR101 powers a Versamax PLC rack controlling conveyor systems. The 20-millisecond holdup time prevents processor resets during momentary voltage dips, maintaining production continuity. In process control, the module serves as a supplemental power source when connected to a power supply booster carrier, distributing additional current to remote I/O racks. The short circuit and overload protection features reduce the risk of cascading failures in densely populated cabinets.
Installation & Setup Guidance
For reliable installation, mount the IC200PWR101 securely onto the Versamax backplane. Verify that the input voltage matches the available AC supply (120 or 240 Volts AC). The jumper installation and voltage range determine the input voltage selection. Ensure the total output current does not exceed 1.5 Amperes maximum. When used as a supplemental power source, connect the module to a power supply booster carrier. Follow standard industrial wiring practices for AC power connections.
Maintenance & Reliability
From a maintenance engineer's perspective, the IC200PWR101 offers straightforward serviceability. Regularly inspect the module for signs of dust accumulation or loose connections. The short circuit and overload protection reduce the likelihood of unexpected shutdowns. Verify that the ambient temperature stays within the Versamax system's specified range. Periodically check the input power (27 volt-amperes) and output voltages (5 Volts DC and 3.3 Volts DC) using a calibrated multimeter to confirm proper operation.
Compatibility & Integration
The IC200PWR101 integrates seamlessly with the GE Fanuc Versamax series. It supplies power to network interface units, I/O units, and central processing units installed on the PLC rack backplane. The module can operate as both a main and a supplemental power source. When connected to a power supply booster carrier, it serves as a supplemental power source. This flexibility allows for scalable system designs.
Selection Guide & Purchasing Advice
Before purchasing the IC200PWR101, verify that your Versamax rack configuration requires a 120/240 Volts AC input power supply. Confirm that the total output current demand of all backplane modules does not exceed 1.5 Amperes maximum. If you need extended power, note that this module has Extended Power set to No. For current availability and lifecycle status, please contact SpareTechPLC. We stock this active model and can provide replacement options if needed.
Frequently Asked Questions
Q: What is the input voltage range for the IC200PWR101?
A: The input voltage is 120/240 Volts AC, selectable via jumper installation.
Q: What output voltages does this module provide?
A: It provides 5 Volts DC and 3.3 Volts DC.
Q: What is the total output current capacity?
A: The total output current is 1.5 Amperes maximum.
Q: Does the IC200PWR101 offer overload protection?
A: Yes, it provides short circuit and overload protection.
Q: Can this module be used as a supplemental power source?
A: Yes, when connected to a power supply booster carrier, it serves as a supplemental power source.
